5
One pair of satellites has 9 feet
(3 meter) cables and one pair has
12 feet (4 meter) cables. Typically,
the satellites in the rear will
require longer cable lengths,
but the satellites are otherwise
identical. If you need extra cable
length for the front channel
satellites, use the ones with
longer cable there instead.
A panel of eight self-adhesive
labels is provided to identify each
satellite. To start, apply the small,
square “FRONT RIGHT” label to the
back of a satellite (see diagram A).
Then wrap the remaining, longer
“FRONT RIGHT” label around the
satellite cable just behind the plug
(see diagram B).
Insert the satellite’s plug into
the corresponding output jack on
the subwoofer (see Speaker Wiring
Diagram).
Repeat the process for the
remaining three satellites.
Satellite Connections
FRONT
LEFT
FRONT
LEFT
REAR
LEFT
FRONT
LEFT
REAR
LEFT
REAR
RIGHT
FRONT
RIGHT
REAR
RIGHT
FRONT
RIGHT
FRONT
LEFT
REAR
LEFT
FRONT
RIGHT
REAR
RIGHT
B
A
