PLAYING COMPACT DISCS
1. Select FUNCTION SELECTOR SWITCH to MODE.
2. Press the CD door open button to open the CD DOOR. Put a CD into
the CD COMPARTMENT and close the CD DOOR.
3. When the CD DOOR is closed, the disc will automatically begin
playback.
4. If the CD DOOR is not closed or there is no disc inside, the DISPLAY
will show "OPN" or "NOd".
NOTE: This unit can read CD-RW discs, however not all types of CD-RW
discs are compatible.
PLAYING COMPACT DISCS WITH MP3/WMA FILES
1. Select FUNCTION SELECTOR SWITCH to MODE.
2. Press the CD door open button to open the CD DOOR. Put an MP3
disc into the CD COMPARTMENT and close the CD DOOR.
3. When the CD DOOR is closed, the disc will automatically begin
playback.
4. Use the REW and F.F. buttons to skip between tracks. If some les
are within folders on the disc, use the FOLDER+ button to enter each
folder and play the les.
5. If the CD DOOR is not closed or there is no disc inside, the DISPLAY
will show "OPN" or "NOd".
NOTE: This unit can read and play compact discs with MP3 and WMA
les on them, however not all such discs and letypes are compatible.
5.4 PLAYING FROM USB / SD STORAGE MEDIA
To play les from USB/SD storage media, follow these steps:
1. Slide the FUNCTION SELECTOR SWITCH to the MODE position.
2. Remove the rubber cover of the USB Connector
3. Before connecting the USB/SD media to the unit, make sure the port
is in the correct direction and will connect. Then connect the USB
Storage Media or SD card.
4. Press CD/USB/SD button to switch function between operation of the
CD, USB, and SD card. The LCD will indicate with text and an icon,
which mode it is in.
5. The system will automatically start playing the les on the USB / SD
card.
6. Use the REW and F.F. buttons to skip between tracks. If some les
are within folders on the disc, use the FOLDER+ button to enter each
folder and play the les. The folder number will ash for 3 seconds.
NOTES:
• It is not possible to operate the USB/SD functions when the CD door
is open. Make sure the CD door is closed during USB/SD Playback.
• This system is able to playback most MP3 and WMA format les
stored on the memory media with a USB connector and SD Card.
This includes the Califone
®
8100 MP3 Player/Recorder using a
standard USB cable and iPod
®
devices using appropriate iPod
®
dock
connector to USB connector.
• When the PLAY/PAUSE button is pressed while playback is stopped,
the rst track will be played. The LCD DISPLAY will show the specic
number of track being played.
CAUTION: Improperly connecting the USB Storage Media or SD/MMC
Card upside down could damage the unit or the USB Storage Media or
SD/MMC Card.
5.5 MISC FUNCTIONS
SKIP AND SEARCH MODE
• During Play or Pause mode, press the UP/F.F. or DN/REW button
once to go to next track or previous track.
• During Play or Pause mode, press and hold the UP/F.F. or DN/REW
button to search within a track and the elapsed time will be shown on
the Display.
• Release the UP/F.F. or DN/REW button once the desired time is
reached.
PROGRAM MODE
1. First, press the STOP button to ensure that playback is stopped.
Note that it is not possible to program while the CD/USB/SD are
playing.
2. Press the PROG button, the display will show "P01" and "000" in
ashing. “P01” for the program location, and “000” for your desired
songs.
3. Then press UP/F.F. or DN/REW. button to search for the track to be
stored.
4. Press the PROG button to store the track.
5. Continue entering tracks in this way until all the desired tracks are
stored (up to a limit of 20 tracks).
6. Press the PLAY/PAUSE button once to start playing the rst
programmed track.
7. During the playback of Programmed tracks, the PROG Indicator on
the LCD display will remain lighted.
8. To clear/stop programmed play, press the STOP button.
