Table D-2 Scan codes with left Shift key
Code set 1 Code set 2Cap
No.
Key
top
Make Break Make Break
55 / E0AAE035E0B5E02AE0F012E04AE0F04AE012
75 INS E0AAE052E0D2E02AE0F012E070E0F070E012
76 DEL E0AAE053E0D3E02AE0F012E071E0F071E012
79
←
E0 AA E0 4B E0 CB E0 2A E0 F0 12 E0 6B E0 F0 6B E0 12
80 Home E0 AA E0 47 E0 C7 E0 2A E0 F0 12 E0 6C E0 F0 6C E0 12
81 End E0AAE04FE0CFE02AE0F012E069E0F069E012
83
↑
E0 AA E0 48 E0 C8 E0 2A E0 F0 12 E0 75 E0 F0 75 E0 12
84
↓
E0 AA E0 50 E0 D0 E0 2A E0 F0 12 E0 72 E0 F0 72 E0 12
85 PgUp E0 AA E0 49 E0 C9 E0 2A E0 F0 12 E0 7D E0 F0 7D E0 12
86 PgDn E0 AA E0 51 E0 D1 E0 2A E0 F0 12 E0 7A E0 F0 7A E0 12
89
→
E0 AA E0 4D E0 CD E0 2A E0 F0 12 E0 74 E0 F0 74 E0 12
203 Win E0AAE05BE0DBE02AE0F012E01FE0F01FE012
204 App E0AAE05DE0DDE02AE0F012E02FE0F02FE012
Note: The table above shows scan codes with the left Shift key. In combination with the
right Shift key, scan codes are changed as listed below.
With left Shift With right Shift
Set 1 E0 AA ___________E0 B6
E0 2A ____________E0 36
Set 2 E0 F0 12 _________E0 F0 59
E0 12 ____________E0 59
No. 55 key: only in the overlay mode (including a temporary overlay mode)
