Index to Parts and Controls (Continued)
Introduction
Display
1 PDC indicator (Programme Delivery Control
System)
Illuminates when setting a PDC controlled
programme recording.
2 PBC indicator
Illuminates when PBC function is “On”
page
138 and a PBC-controllable VIDEO CD is loaded.
3 Programmed recording icon
Illuminates when programmed recording is set.
4 Angle icon
page 57
Illuminates when playing a scene recorded with
multi angles.
5 Track indicator
Illuminates when the track number is displayed.
6 Remain icon
Illuminates when the remaining time is displayed.
7 Bit rate indicator
Illuminates when displaying the bit rate value
specified for recording or the actual bit rate value
used for playback.
8 Title indicator
Illuminates when displaying the title number.
9 Chapter indicator
Illuminates when displaying the chapter number.
! NICAM indicator
Illuminates when NICAM function is “ON”
page
140 and while receiving stereo/mono programmes
of NICAM broodcasts.
" Analog output level indicator
Displays the analog output level.
L+R: Stereo and bilingual (left (main) channel and
right (sub) channel)
L: Left (main) channel
R: Right (sub) channel
Off: Mono
Level indicator may not show exact sound level. It
only shows the average level.
LPressing the DIMMER button on the remote control changes the brightness of the display (normal/dimmed/off).
LEvery time you press the FL SELECT button, the display changes between the channel, title number, and time. The
display may not change, depending on the disc or recording conditions.
1 65 97 83 42
10
111215 14 13
