About the indicators on the display
LPCM NIGHT SLEEP HDMI COAX OPT TUNED ST S-AIR MUTING DTS
PL
D
1 6578423
9q;qa
Name Function
A LPCM Lights up when Linear PCM
(Pulse Code Modulation) signals
are input.
B NIGHT Lights up when the Night Mode
function is set to on (page 36).
C SLEEP Lights up when the sleep timer is
activated (page 65).
D Input
indicators
HDMI
COAX
OPT
Light up when the digital signal
is input.
Digital signal is input through
the HDMI IN jack.
Digital signal is input through
the COAX IN jack.
Digital signal is input through
the OPT IN jack.
E Tuning
indicators
TUNED
ST
Light up to indicate the current
status of the radio station
(page 36).
When receives a radio station.
When broadcasts in stereo mode.
F S-AIR Lights up when the S-AIR
transmitter (not supplied) is
connected.
G MUTING Lights up when the muting
function is activated (page 31).
Name Function
H DTS Lights up when the system is
decoding DTS signals.
Note
When playing a DTS format
disc, be sure that you have made
digital connections.
I Message
display area
Displays the volume level,
selected input source, audio
input signal, etc.
J D Lights up when the system is
decoding Dolby Digital signals.
Note
When playing a Dolby Digital
format disc, be sure that you
have made digital connections.
K Dolby Pro
Logic
indicators
PL
PLII
Light up one of the respective
indicators when the system
applies Dolby Pro Logic
processing to 2 channel signals
in order to output the center and
surround channel signals.
Dolby Pro Logic
Dolby Pro Logic II
continued
