Sample Configurations 257
10233
Client
s
Disk 1 Disk 2
Disk 4
V Switch
Manager and
Host Station
RS232
Connection
Fibre Channel
Connection
Windows 2000
Microsoft Initiator
1
2
1 Gbit Ethernet,
RJ45 Copper
Connection
3
Disk 3
Disk 5
JBOD 1
Figure 104. Replacing a Failed Disk
STEP 1. S
ELECT A REPLACEMENT DISK
Insert a replacement blade of the same size according to your specific
manufacture’s instructions
