COLOR DOME CAMERA User Guide
30
COLOR DOME CAMERA User Guide
31
direction of the Function Setup Switch and then press the Function Setup Switch.
Increase or decrease iris level by moving the left or right direction of the Function
Setup Switch while verifying the changes on screen.
Operating Your Camera
IRIS AUTO SETUP
▶
OPEN LIMIT
938
CLOSE LIMIT 1
RETURN
IRIS MANUAL SETUP
▶
IRIS F-No F1.6
IRIS MAN 1023
RETURN
SHUTTER MANUAL SETUP
▶
SHUTTER VAL 1/50
RETURN
GAIN MANUAL SETUP
▶
AGC VAL 5dB
RETURN
SSNR
▶
LEVEL 12
RETURN
|
|||||||||||||||||||||||||
||||||||||||||||||||
|
|||
|||||||||||||||||||||||
|
SHUTTER:Controlimagebrightnessbyadjustingshutterspeed.
Positiontheindicatorover'SHUTTER'bymovingtheupordowndirectionofthe
Function Setup Switch. Then select the desired shutter mode (A.FLK, ESC, MANUAL)
by moving the up or down direction of the Function Setup Switch.
If you choose ’MANUAL‘, select the optimal shutter
speed.
- In MANUAL mode, the optimal shutter speed needs
tobedesignated.Selectfrom1/60to1/120,000
(NTSC) or from 1/50 to 1/120,000 (PAL). * 'Sens-Up'
mode can be configured manually (2x to 512x).
- Verify changes made to the shutter speed by
referencing to changes the 'on-screen' brightness.
Press the Function Setup Switch to complete.
EXPOSURE SETUP
BRIGHTNESS 50
IRIS AUTO
SHUTTER ---
AGC HIGH
||||||||||||
|
|||||||||||||
- MANUAL : Manual shutter speed setting.
- A.FLK (NTSC: 1/100, PAL: 1/120) : Flicker-free mode.
- ESC : Automatic shutter speed setting (optimal).
Auto operation is possible only when the IRIS is set to MANUAL.
•Imagemaybecomeunstableifthecameraissetto'ESC'modeandfacesastrong
fluorescentlight.
•Under'ESC'mode,thebrightnesscanbeadjustedbymovingtheleftorrightdirection
oftheFunctionSetupSwitch
Notes
AGC (Auto Gain Control) : For brighter images.
Position the indicator over 'AGC' by moving the up or down direction of the Function
Setup Switch.
Set 'AGC' to the desired mode by moving the left or right direction of the Function
Setup Switch.
-HIGH:Widerangegainvalueadjustment
-MANUAL:Selectinggainvaluerange.(5dB~41dB)
- OFF : Disabled
- LOW : Narrow range gain value adjustment
- MEDIUM : MEDIUM range gain value adjustment
SSNR(Samsung Super Noise Reduction) : On screen noise reduction.
Positiontheindicatorover'SSNR3'bymovingtheupordowndirectionofthe
Function Setup Switch.
Set'SSNR3'tothedesiredmodebymovingtheleftor
right direction of the Function Setup Switch.
- OFF : Disabled
EXPOSURE SETUP
BRIGHTNESS 50
IRIS AUTO
SHUTTER ---
AGC HIGH
SSNR3 ON
||||||||||||
|
|||||||||||||
||||||||||||||||||||||||
|
