Connected Device Name
36
ENGLISH
Using the Bluetooth cellular phone
Adjusts the volume of the incoming calls.*
3
☞ page 38
Sound mode
(☞ page 55)
Status of the device
Signal strength/Battery
remainder (only when
the information comes
from the device)
Bluetooth icon lights
up when the adapter
is connected.
*
1
When a call comes in...
The source is changed to “Bluetooth PHONE”
automatically.
Name and phone number (if acquired)
When <Auto Answer> is activated...
The unit answers the incoming call automatically.
(☞ page 65)
When <Auto Answer> is deactivated...
To answer the incoming call
• Press the message displayed on the touch panel.
• Press any button on the monitor panel (except
/ATT or VOL +/–).
To end the call
• Hold the message displayed on the touch panel.
• Hold any button on the monitor panel (except
/ATT or VOL +/–).
• You can adjust the microphone volume. (☞ page 65)
*
1
When a cellular phone with audio function is connected, appears.
*
2
This button appears when the Bluetooth Adapter is connected.
*
3
This adjustment does not affect the volume level of the other sources.
~ Press [SOURCE], then press [Bluetooth PHONE]. (☞ page 11)
• You can also use SOURCE on the monitor panel. Press it repeatedly.
Ÿ Press [ ].
• You can also use MENU on the monitor panel.
! Press [Bluetooth].
⁄ Establish the connection with a device, then make a call (or settings using <Bluetooth>
menu).
(☞ pages 64 and 65)
[5 ∞] Selects the registered device
(“NEW DEVICE” appears when a new device can be registered.)
[ ] Hold: Activates <Voice Dialing> function
[ ] Displays <
Dial Menu
> screen.
*
2
