INDEX
REFERENCES
EN 37
MasterPage: Ref_Right
Controls
a Menu Wheel [MMENU/VOL.] (੬ pg. 15)
Speaker Volume Control [MMENU/VOL.] (੬ pg. 13)
b Snapshot Button [SNAPSHOT] (੬ pg. 21)
c Power Zoom Lever [T/W] (੬ pg. 11)
d Manual Focus Button [FOCUS] (੬ pg. 22)
Blank Search Button [BLANK SRCH] (੬ pg. 13)
e Diopter Adjustment Control (੬ pg. 8)
f Recording Start/Stop Button (੬ pg. 10)
g Power Switch [A, M, PLAY, OFF] (੬ pg. 8)
h Lock Button (੬ pg. 8)
i Stop Button [8] (੬ pg. 13)
j Rewind Button [
3
] (੬ pg. 13)
Night Button [NIGHT] (੬ pg. 19)
k Play/Pause Button [4/9] (੬ pg. 13)
l Fast-Forward Button [
5
] (੬ pg. 13)
Backlight Compensation Button [BACKLIGHT]
(੬ pg. 23)
m Battery Release Switch [BATT.RELEASE] (੬ pg. 6)
n Cassette Open/Eject Switch [OPEN/EJECT] (੬ pg. 9)
o White LED Light Switch [LIGHT] (੬ pg. 19)
p Monitor Opening Button (੬ pg. 11)
For models without button, simply pull on bottom end
of LCD monitor to open.
Connectors
Q S-Video Output Connector [S-VIDEO] (੬ pg. 14, 24)
R Digital Video Connector [DV] (i.Link*) (੬ pg. 25, 26)
S Audio/Video Output Connector [AV] (੬ pg. 14, 24)
T DC Input Connector [DC] (੬ pg.6,7)
* i.Link refers to the IEEE1394-1995 industry specification
and extensions thereof. The logo is used for products
compliant with the i.Link standard.
Indicators
U POWER/CHARGE Lamp (੬ pg.8,10)
Other Parts
V Shoulder Strap Eyelet (੬ pg. 5)
W Battery Pack Mount (੬ pg. 7)
X Grip Strap (੬ pg. 7)
Y LCD Monitor (੬ pg. 11, 12)
Z Speaker (੬ pg. 13)
a Stud Hole (੬ pg. 9)
b Tripod Mounting Socket (੬ pg. 9)
c Cassette Holder Cover (੬ pg. 9)
d Stereo Microphone
e White LED Light (੬ pg. 19)
f Viewfinder (੬ pg. 8)
g Camera Sensor
(Be careful not to cover this area, a sensor necessary
for shooting is built-in here.)
