Screw Listing
Maintenance and Service Guide C–7
Phillips M2.5×8.0 Screw Locations
Table C-4
Phillips PM2.5×8.0 Screw
Color Qty. Length Thread
Head
Width
Black 26 8.0 mm 2.5 mm 5.0 mm
Where used:
1 One screw that secures the keyboard to the notebook in the memory
module/Mini PCI compartment (documented in Section 5.8)
2 Three screws that secure the top cover to the notebook: 2 on the front edge
of the notebook, one in the battery bay (documented in Section 5.11)
mm
