6Ć46 Removal and Replacement
C4699Ć90000
Removing the Overdrive
Enclosure
1 Remove the right endĆcover ' page 6Ć10.
Remove the spittoon ' page 6Ć24.
2 Remove the overdrive roller ' page 6Ć32.
3 Remove the indicated two screws from
the right sideĆplate.
Torx-15
1
2
This illustration shows the configuration
for the DesignJet 230/250C. The removal
procedure for DesignJet 330/350C is
exactly the same except that the spittoon
has been removed to access the indicated
screws.
4 Remove the indicated three screws from
the left sideĆplate.
Torx-15
3
4
5
5 Lift the overdrive enclosure out from the
plotter.
Reassembling: See following procedure.
