22
Using the Configuration Menu Functions
The configuration menus can be used to carry out a variety of settings and adjustments. The menus have a hierarchical
structure, with a main menu that is divided into sub-menus, which are further divided into other sub-menus.
The remote control is used to operate the menus. Refer to “Using the Configuration Menus” (p.29) for details on using the
menus.
•
The functions in the Video menu other than EPSON Cinema Filter, Input Signal, Auto Setup and Video
Signal cannot be adjusted when no image signal is being input.
•
The functions that appear in the Video menu change depending on the type of input source being used for
the image signal. Functions that are not available in the Video menu for a particular input source cannot be
adjusted.
Video Menu
Video Menu
Video (S-Video, Composite video, Component)
Sub-menu Function Default
EPSON Cinema
Filter
This turns the function on and off for automatically adjusting signals to the
optimum tint for movie images.
When set to ON, the proper effect will not be obtained unless the EPSON
cinema filter is attached to the lens of the projector. (p.15)
OFF
Position Moves the image display position vertically and horizontally.
•
Press the [Enter] button and make the adjustment using the display position
adjustment sub-menu that appears.
Depends on
connection
Brightness Adjusts the image brightness. Median
value (0)
Contrast
Adjusts the difference between light and shade in the images. Median
value (0)
Color (Not available for RGB video)
Adjusts the color intensity for the image.
Median
value (0)
Adjust
+
-
+
-
+
-
+
-
+
-
: Select : Enter
4
:
3 16
:
9
Video
Audio
Setting
Advanced
About
Reset All
Video Signal
Color Mode
Position
Brightness
Contrast
Color
Tint
Sharpness
Aspect Ratio
Reset
:
:
:
:
:
:
:
0
0
0
0
0
Select
Select
Execute
[Theatre ]
[Auto ]
EPSON Cinema Filter :
ON OFF
Main menu Sub-menu (Video)
: Select : Enter
Adjust
+
-
+
-
+
-
4
:
3 16
:
9
+
-
+
-
Video
Audio
Setting
Advanced
About
0
0
0
0
Reset All
0
Input Signal
Color Mode
Position
Brightness
Contrast
Color
Tint
Sharpness
Aspect Ratio
Reset
:
:
:
:
:
:
:
Select
RGB
YUV( YCbCr YPbPr)
Execute
[Theatre ]
EPSON Cinema Filter :
ON OFF
Adjust
+
-
+
-
+
-
+
-
+
-
: Select : Enter
4
:
3 16
:
9
Video
Audio
Setting
Advanced
About
Reset All
Video Signal
Color Mode
Position
Brightness
Contrast
Color
Tint
Sharpness
Aspect Ratio
Reset
:
:
:
:
:
:
:
0
0
0
0
0
Select
Select
Execute
[Theatre ]
[Auto ]
EPSON Cinema Filter :
ON OFF
Component (YCbCr , YPbPr )Video (S-Video, Composite video)
