Front Panel Operation
5-26
IMPORTANT!
•
Every time you change channel mode, you must reset the controller for the
changes to take effect.
Setting a SCSI Channel’s ID - Host Channel
Viewing IDs
Press ENT for two seconds to enter the
Main Menu. Press ▼ or ▲ to select
"View and Edit SCSI Channels," then
press ENT.
Channel information will be displayed.
Press ENT on the host channel you
wish the ID changed.
Press ▼ or ▲ to select “Set SCSI
Channel ID," then press ENT.
Press ▼ or ▲ to browse through the
existing ID settings. Press ENT on any
to continue.
Adding a Channel ID
Press ENT on a host channel, on “Set
SCSI Channel ID”, and then on an
existing ID.
Press ▼ or ▲ to choose “Add Channel
SCSI ID", then press ENT.
Press ▼ or ▲ to choose “Primary
Controller” or “Secondary Controller”,
then press ENT for two seconds to
confirm.
Press ▼ or ▲ to choose the SCSI ID you
wish to add, then press ENT for two
seconds to complete the process.
View and Edit
SCSI Channels ↕
CH0=Host PID=0
SID=NA SXF=20.0M
Set SCSI Channel
ID ..
Primary
Controller ?
Add CHL=0 ID=2
Primary Ctlr ?
CHL=0 ID=0
Primary Ctrl ..
Add Channel
SCSI ID ..
