Configuration of the camera
OSCAR Technical Manual V2.4.0
196
Mirror image
The table below illustrates the advanced register for Mirror image.
Soft Reset
The SOFT_RESET feature is similar to the INITIALIZE register, with the follow-
ing differences:
1 or more bus resets will occur.
The FPGA will be rebooted.
The reset can be delayed by setting the Delay to a value unequal to 0.
The delay is defined in 10 ms steps.
Register Name Field Bit Description
0xF1000410 MIRROR_IMAGE Presence_Inq [0] Indicates presence of this
feature (read only)
--- [1..5] Reserved
ON_OFF [6] Mirror image on/off
1: on
0: off
Default: off
--- [7..31] Reserved
Table 99: Advanced register: Mirror
Register Name Field Bit Description
0xF1000510 SOFT_RESET Presence Inquiry [0] Indicates presence of this
feature (read only)
--- [1..5] Reserved
Reset [6] Initiate reset
--- [7..19] Reserved
Delay [20..31] Delay reset in 10 ms steps
Table 100: Advanced register: Soft reset
Note
L
When SOFT_RESET has been defined, the camera will respond
to further read or write requests, but will not process them.
