Softkey/Programmable Key/Keypad Key/Feature Key/Expansion Module Key/Hard Key
A-171 41-001343-02 REV04 – 05.2014
• phonelock - Indicates the key is configured to be used to lock/unlock the phone.
• paging - Indicates the key is configured for Group Paging on the phone. Pressing this
key automatically sends a Real Time Transport Protocol (RTP) stream to pre-config-
ured multicast address(es) without involving SIP signaling.
• empty - Indicates the key is configured to force a blank entry on the IP phone display
for a specific key.
The softkeys are added in order (from softkey1 to softkey20) after any hardcoded keys
have been added. If a particular softkey is not defined, it is ignored.
Format Text
Default Value none
Range • none
• line
• speeddial
• dnd
• blf
• list ("BLF/List" in the Aastra Web UI)
• acd (“Auto Call Distribution” in the Aastra Web UI)
• dcp (“Directed Call Pickup” in the Aastra Web UI)
• xml
• flash
• sprecode
• callforward
• park
• pickup
• blfxfer
• speeddialxfer
• speeddialconf
• speeddialmwi
• lcr
• directory
• filter
• callers (“Callers List” in Aastra Web UI)
• redial
• conf
• xfer
• icom
• services
• phonelock
• paging
• empty
Example topsoftkey1 type: line
topsoftkey2 type: speeddial
topsoftkey3 type: lcr
topsoftkey4 type: xml
