ENGLISH
Indications Selectable settings, [reference page]
TA VOL
Traffic announcement
volume
[Initial: VOL 15]; VOL 00 — VOL 30 or 50*
1
, [10]
P-SEARCH
Programme search
ON : Using the AF data, the unit tunes in to another frequency
broadcasting the same programme as the original
preset RDS station is if the preset station signals are not
sufficient.
OFF : [Initial]; Cancels.
DAB AF*
2
Alternative frequency
reception
AF ON : [Initial]; Traces the programme among DAB services
and FM RDS stations, [11, 22].
AF OFF : Cancels.
DAB VOL*
2
DAB volume
adjustment
You can adjust the volume level (VOL –12 — VOL +12) of DAB tuner
to match the FM sound level and store it in memory.
[Initial: VOL 00]
LEVEL
Audio level meter
ON : [Initial]; Activates the audio level indicator.
OFF : Cancels; sound mode indicator is shown.
DIMMER
Dimmer
AUTO : [Initial]; Dims the display when you turn on the
headlights.
ON : Activates dimmer.
OFF : Cancels.
TEL
Telephone muting
MUTING 1/MUTING 2 : Select either one which mutes the sounds
while using a cellular phone.
OFF : [Initial]; Cancels.
SCROLL*
3
Scroll
ONCE : [Initial]; Scrolls the track information once.
AUTO : Repeats scrolling (5-second intervals in between).
OFF : Cancels.
• Pressing DISP for more than one second can scroll the display
regardless of the setting.
WOOFER
Subwoofer cutoff
frequency
LOW : Frequencies lower than 90 Hz are sent to the subwoofer.
MID : [Initial]; Frequencies lower than 135 Hz are sent to the
subwoofer.
HIGH : Frequencies lower than 180 Hz are sent to the subwoofer.
EXT IN*
4
External input
CHANGER : [Initial]; To use a JVC CD changer, [11], an Apple iPod
or a JVC D. player, [19].
EXT IN : To use any other external component than the above,
[20].
*
1
Depends on the amplifier gain control (see page 18).
*
2
Displayed only when DAB tuner is connected.
*
3
Some characters or symbols will not be shown correctly (or will be blanked) on the display.
*
4
Displayed only when one of the following sources is selected—FM, AM, CD, or USB.
Continued on the next page
