English
To install the car handsfree
1 Disconnect the car battery.
2 Place the electronic box under the dashboard
of the car. See also installation chart on page 2.
It is recommended that the upper side of the
electronic box faces the driver with no metallic
barrier between the box and the driver. Use the
velcro enclosed in the kit to fasten the
electronic box.
} Connect the bundle of power cables
(red and black), music mute cable (yellow)
and ignition sense cable (blue) to the electronic
box .
3 Connect the black power cable to negative
ground. Connect the red power cable, with the
integrated fuse, to the positive pole on the
car battery. Please note that supply voltages
other than 12 volts may cause damage to
the equipment.
4 Connect the yellow music mute cable to the
car stereo. See A in installation chart on
page 2.
5 Connect the blue ignition sense cable to the
ignition of the car. See B in installation chart
on page 2.
6 Place the microphone on a fixed part of the
car interior, preferably in the middle above the
wind screen. Place it directed towards the
driver and away from the loudspeaker(s).
Place it away from air flows such as windows
and ventilation. Make sure that the cable is
long enough to reach the electronic box.
Connect the microphone to the electronic
box .
7 Place the loudspeaker at least 50 cm
(20 inches) from the microphone. Make sure
that the cable is long enough to reach the
electronic box. Connect the external
loudspeaker to the electronic box .
8 Choose a suitable location on the dashboard
of the car for the control panel. The driver
must be able to reach the keys of the control
panel from the normal driving position. Make
sure that the cable is long enough to reach the
electronic box. Remove the adhesive tape from
the control panel. Place the control panel in the
location you have chosen. Connect the control
panel to the electronic box .
9 Connect the car battery.
