Preparation
11
GB
4 Rest the headphones on the processor so that the headphones’ contact point
meets the processor’s contact pin while making sure that the CHG indicator
lights up.
It takes approx. 16 hours to fully charge the battery (the CHG indicator goes off
when charging is complete).
When placing the
headphones on the processor,
be sure to hold them with
both hands so that the right
and left housings are
horizontal. Place the
headphones vertically on the
processor then tilt them back
as illustrated below.
If the CHG indicator is not lit
Check if the right and left headphones are rested on the processor correctly. The
indicator will not light up if the headphones’ contact point does not meet the
processor’s contact pin. In this case, remove the headphones and place them on the
processor again so that the indicator lights up.
To recharge the headphone battery after use
Place the headphones on the processor after you use the headphones. The CHG
indicator lights up, and the DECODE MODE indicator goes off, and then charging
starts.
Since the built-in timer recognizes when charging is complete (approx. 16 hours),
there is no need to remove the headphones from the processor after charging has
completed.
Notes
• The processor automatically turns off while charging the batteries.
• This system is designed to charge only the supplied rechargeable batteries, type BP-HP550 for
safety. Note that other types of rechargeable batteries cannot be charged with this system.
• If dry batteries are installed, they cannot be charged.
• Do not attempt to use the supplied BP-HP550 rechargeable batteries for other components.
They are for use with this system only.
• Charge in an environmental temperature of between 0˚C and 40˚C (between 32˚F and 104˚F).
Charging and usage hours
Approx. charging hours Approx. usage time*
1
1 hour 1 hour and 15 minutes*
3
16 hours*
2
20 hours*
3
*
1
at 1 kHz, 1 mW + 1 mW output
*
2
hours required to fully charge empty batteries
*
3
Time stated above may vary, depending on the temperature or conditions of use.
Right
housing
Left housing
Contact
point
Contact pin
