69
GB
Specifications
Amplifier Section
BDV-F700:
POWER OUTPUT (rated)
Front L/Front R: 85 W + 85 W (at 4 ohms, 1
kHz, 1% THD)
POWER OUTPUT (reference)
Front L/Front R: 130 W (per channel at 4
ohms, 1 kHz)
Subwoofer: 140 W (at 4 ohms, 100 Hz)
BDV-F500:
POWER OUTPUT (rated)
Front L/Front R: 80 W + 80 W (at 4 ohms, 1
kHz, 1% THD)
POWER OUTPUT (reference)
Front L/Front R: 115 W (per channel at 4
ohms, 1 kHz)
Subwoofer: 120 W (at 4 ohms, 100 Hz)
Inputs (Analog)
AUDIO (IN) Sensitivity: 450/250 mV
Inputs (Digital)
SAT/CABLE (DIGITAL IN OPTICAL),
TV (DIGITAL IN OPTICAL)
Supported formats: LPCM
2CH (up to 48 kHz), Dolby
Digital, DTS
Video Section
Outputs VIDEO OUT: 1 Vp-p 75
ohms
HDMI OUT: Type A (19
pin)
BD/DVD/Super Audio CD/CD System
Signal format system PAL/NTSC
USB Section
(USB) port: Type A (For connecting
USB memory, memory
card reader, digital still
camera, and digital video
camera)
Maximum current: 500 mA
LAN Section
LAN (100) terminal 100BASE-TX Terminal
Tuner Section
System PLL quartz-locked digital
synthesizer
FM tuner section
Tuning range 87.5 MHz - 108.0 MHz
(50 kHz step)
Antenna (aerial) FM wire antenna (aerial)
Antenna (aerial) terminals 75 ohms, unbalanced
Intermediate frequency 10.7 MHz
Speakers
Front (SS-TSF770) for BDV-F700
Speaker system 2-Way 2-Driver Bass
reflex
Speaker unit
Tweeter: 20 mm cone type
Woofer: 40 mm × 70 mm cone type
Rated impedance 4 ohms
Dimensions (approx.)
Floor: 200 mm × 1,100 mm ×
230 mm (w/h/d) (vertical
angle)
200 mm × 1,100 mm ×
255 mm (w/h/d) (upward
angle)
Desktop: 103 mm × 335 mm ×
103 mm (w/h/d) (vertical
angle)
103 mm × 360 mm ×
109 mm (w/h/d) (upward
angle)
Mass (approx.)
Floor: 2.9 kg
Desktop: 0.6 kg
Front (SS-TSF550) for BDV-F500
Speaker system 2-Way 2-Driver Bass
reflex
Speaker unit
Tweeter: 20 mm cone type
Woofer: 50 mm cone type
Rated impedance 4 ohms
Dimensions (approx.) 76 mm × 270 mm × 85 mm
(w/h/d) (vertical angle)
76 mm × 270 mm × 90 mm
(w/h/d) (upward angle)
Mass (approx.) 0.8 kg
Subwoofer (SS-WSF550)
Speaker system Subwoofer Bass reflex
Speaker unit 160 mm cone type
Rated impedance 4 ohms
Dimensions (approx.) 265 mm × 335 mm × 265
mm (w/h/d)
Mass (approx.) 6.5 kg
General
Power requirements
European models: 220 V - 240 V AC,
50/60 Hz
Latin American models: 110 V - 240 V AC,
50/60 Hz
Power consumption
European models: On: 85 W
Standby: 0.3 W (at the
Power Saving mode)
