SPECIFICATIONS
Stereo Continuous Output Power: 75W per channel at 8 ohms
100W per channel at 4 ohms
Bridged Output Power: 200W at 8 ohms, 2 channels bridged
THD+N: <0.05% from 20Hz to 20kHz
Signal-to-Noise Ratio: >100dB A-weighted
Frequency Response: 20Hz to 20KHz +/- 0.3dB
Input Sensitivity: 70mV for 1W at 8 ohms
610mV for 75W at 8 ohms
Input Impedance: 47kohms Line Input
Voltage Gain: 32dB
Power Requirements:
North American Model:
120VAC 60Hz 2.5A
IEC 320 type connector with 3 terminal detachable power cord.
Power Requirements:
European Model:
230VAC 50Hz 1.2A
IEC 320 type connector with 3 terminal detachable power cord.
Dimensions: 17" W x 14"D x 4.125"H (43 x 35.5 x 10.5 cm)
Weight: 20.3lbs. (9.2kg)
WARRANTY
The Russound R275HC is fully guaranteed for two (2) years from the date of purchase against all defects in materials
and workmanship. During this period Russound will replace any defective parts and correct any defect in workman-
ship without charge for either parts or labor. For this warranty to apply, the unit must be installed and used according
to its written instructions. If service is necessary, it must be performed by Russound. The unit must be returned to
Russound at the owners expense and with prior written permission. Accidental damage and shipping damage are not
considered defects under the terms of the warranty. Russound assumes no responsibility for defects resulting from
abuse or servicing performed by an agency or person not specifically authorized in writing by Russound. Damage to
or destruction of components due to improper use voids the warranty. In these cases the repair will be made at the
owners expense. To return for repairs, the unit must be shipped to Russound at the owners expense, along with a
note explaining the nature of the service required. Be sure to pack in a corrugated container with at least 3 inches of
resilient material to protect the unit from damage in transit.
Russound sells products only through authorized Dealers and Distributors to ensure that customers obtain proper
support and service. Any Russound product purchased from an unauthorized dealer or source, including retailers,
mail order sellers and online sellers will not be honored or serviced under existing Russound warranty policy. Any sale
of products by an unauthorized source or other manner not authorized by Russound shall void the warranty on the
applicable product.
