PLAYING A CD+G (COMPACT DISC + GRAPHICS) KARAOKE DISC
You can listen to a CD+G Karaoke disc. CD+G discs combine the recorded music with an additional video
track that displays the song lyrics on this monitor and/or an external TV, if connected. As the song plays, the
words to be sung are highlighted on most CD+Gs.
NOTES:
• The Program and Repeat features on a CD+G disc operate the same as with a standard CD.
• During playback of a CD+G disc, the CD+G indicator will light. During playback of a non-CD+G disc, the
CD+G indicator will not light.
Insert a CD+G disc. Insert the
microphone(s) into the MIC
jack(s). You can connect the unit
to a TV or TV and stereo as
shown on pages 5-6.
1
Slide the MONITOR switch to ON
to view the On-Screen Graphics
recorded on the CD+G disc on
the monitor.
1
1
3
Press the CD+G PLAY/PAUSE
(®p) button to start CD+G
playback; the PLAY/PAUSE and
CD+G indicators will light.
1
1
4
Press the POWER button to turn
the unit on.
1
1
2
Adjust the MIC VOLUME control(s) ❶ as desired. Increasing these
controls will increase the volume of the microphone(s). Adjust the
ECHO control
❷ to add an echo effect to your voice. The ECHO
control
❷ is variable so add as much or as little reverb as desired.
Sing or talk into the microphone and you will hear both the CD+G
and the microphone.
1
1
2
6
Press the VOCAL AUTO button to activate the Vocal Auto feature.
When activated, the vocals on a multiplex recording are muted as
soon as the singer begins singing into the microphone. When the
singer stops singing, the vocals are automatically unmuted.
IMPORTANT NOTE: This feature only works with multiplex media.
1
1
5
OPERATION (CONTINUED)
