16
Basic operations
IMPORTANT
Before using the remote control for the following
operation;
• Set the remote control mode selector to AUDIO.
On the remote control:
Press F AUDIO.
On the center unit:
Press F.
When DVD is selected as the source (A pg. 17), the following
messages will appear on the TV screen.
NOTE
• The STANDBY lamp turns on when the power is turned off and turns
off when the power is turned on.
• The power supply to the subwoofer is linked to the center unit. The
POWER ON lamp on the subwoofer lights green when the power is
turned on.
• A small amount of the power is consumed even when the power is
turned off (center unit only). This is called standby mode and the
STANDBY lamp lights in this mode. Unplug the power cord from the
AC outlet to turn the power off completely.
• You can also turn on the system by pressing the following buttons;
• OPEN/CLOSE on the remote control or 0 on the center unit
• One of the source selecting buttons on the remote control
• 3 on the center unit. You can use the same buttons on the remote
control except after pressing FM/AM.
The buttons on the remote control are used to explain most of the
operations in this manual. You can use the buttons on the center
unit same as on the remote control for operations unless
otherwise noted.
The buttons described below are used on
pages 16 to 19.
DVD
MUTING
FM/AM
AUDIO VOL
F AUDIO
ENTER
SCAN MODE
SLEEP
S.WFR
SMART
S.SETUP
CENTER
DIMMER
TREBLE
L-SURR.-R
VCR DBS
AUDIO
Source
selecting
buttons
Remote control
mode selector
Cursor
(3/2/Y/5)/
ENTER
VOLUMESTANDBY
PHONES
Turning the system on/off
•“OPEN”/“CLOSE”:
Appears when opening or closing the disc tray.
•“NOW READING”:
Appears when the system is reading the disc information.
•“REGION CODE ERROR!”:
Appears when the Region Code of the DVD VIDEO does not
match the code the system supports. The disc cannot be
played back.
•“NO DISC”:
Appears when no disc is loaded.
•“CANNOT PLAY THIS DISC”:
Appears when unplayable disc is loaded.
TH-S8S5[USUB].book Page 16 Friday, May 28, 2004 2:22 PM
