JVC KD-G421 CD Player User Manual



ENGLISH
21
More about this unit
Basic operations
Turning on the power
By pressing SRC button on the unit, you can
also turn on the power. If the source is ready,
playback also starts.
Turning off the power
If you turn off the power while listening to a
disc, disc play will start from where playback
has been stopped previously, next time you
turn on the power.
Tuner operations
Storing stations in memory
During SSM search...
– All previously stored stations are erased and
stations are stored newly.
– Received stations are preset in No. 1 (lowest
frequency) to No. 6 (highest frequency).
– When SSM is over, the station stored in
No. 1 will be automatically tuned in.
When storing a station manually, the
previously preset station is erased when a new
station is stored in the same preset number.
FM RDS operations
Network-Tracking Reception requires
two types of RDS signals—PI (Programme
Identification) and AF (Alternative
Frequency) to work correctly. Without
receiving these data correctly, Network-
Tracking Reception will not operate correctly.
If a Traffic Announcement is received by
TA Standby Reception, the volume level
automatically changes to the preset level (TA
VOL) if the current level is lower than the
preset level.
5 U (up) / D (down) buttons
Changes the FM/AM/DAB bands with
U (up).
Changes the preset stations with
D (down).
Changes the folder of the MP3/WMA
discs.
While playing an MP3 disc on an
MP3-compatible CD changer:
Changes the disc if pressed briefly.
Changes the folder if pressed and held.
While listening to an iPod or a D. player:
Pauses/stops or resumes playback with
D (down).
Enter the main menu with U (up).
(Now U/D/R/F work as the menu
selecting buttons.)*
6 VOLUME – /+ buttons
Adjusts the volume level.
* U (up) : Returns to the previous menu.
D (down) : Confirms the selection.
The unit is equipped with the steering wheel
remote control function.
See the Installation/Connection Manual
(separate volume) for connection.
To be continued....
