JVC KD-G421 CD Player User Manual



ENGLISH
15
Indications Selectable settings, [reference page]
DAB AF*
3
Alternative frequency
reception
AF ON : [Initial]; Traces the programme among DAB services
and FM RDS stations, [9, 17].
AF OFF : Cancels.
DAB VOL*
3
DAB volume adjustment
You can adjust the volume level (VOL –12 — VOL +12) of DAB
tuner to match the FM sound level and store it in memory.
[Initial: VOL 00]
DIMMER
Dimmer
ON : Dims the display illumination of this unit.
OFF : [Initial]; Cancels.
TEL
Telephone muting
MUTING 1/MUTING 2 : Select either one which mutes the sounds
while using a cellular phone.
OFF : [Initial]; Cancels.
SCROLL*
4
Scroll
ONCE : [Initial]; Scrolls the disc information once.
AUTO : Repeats scrolling (5-second intervals in between).
OFF : Cancels.
Pressing DISP for more than one second can scroll the display
regardless of the setting.
EXT IN*
5
External input
CHANGER : [Initial]; To use a JVC CD changer, [9], an Apple iPod
or a JVC D. player, [17].
EXT IN : To use any other external component than the above,
[19].
TAG DISP
Tag display
TAG ON : [Initial]; Shows the Tag information while playing
MP3/WMA tracks, [11].
TAG OFF : Cancels.
AMP GAIN
Amplifier gain control
You can change the maximum volume level of this unit.
LOW PWR : VOL 00 – VOL 30 (Select this if the maximum power
of the speaker is less than 50 W to prevent them from
being damaged.)
HIGH PWR : [Initial]; VOL 00 – VOL 50
IF BAND
Intermediate frequency
filter
AUTO : [Initial];
Increases the tuner selectivity to reduce
interference noises between close stations. (Stereo
effect may be lost.)
WIDE : Subject to interference noises from adjacent stations,
but sound quality will not be degraded and the stereo
effect will remain.
*
3
Displayed only when DAB tuner is connected.
*
4
Some characters or symbols will not be shown correctly (or will be blanked) on the display.
*
5
Displayed only when one of the following sources is selected—FM, AM, or DISC.
