Operation Manual
Macro-Tech MA-24X6 & 36X12 Power Amplifiers
page 22
Performance (continued) Macro-Tech 24X6 Macro-Tech 36X12
Output Impedance See Figure 7.3 See Figure 7.3
Load Impedance (Note: Safe with all types of loads) 2, 4, 8, 16 ohms 2, 4, 8, 16 ohms
Voltage Gain (8-ohm load, rated output at 1 kHz, maximum level setting)
83:1 ±6% or 38 dB ±0.5 dB (Ch. 1, .775V sensitivity)
54:1 ±6% or 35 dB ±0.5 dB (Ch. 2, .775V sensitivity)
20:1 ±6% or 26 dB ±0.5 dB (Ch. 1, 26 dB gain)
20:1 ±6% or 26 dB ±0.5 dB (Ch. 2, 26 dB gain)
124.6:1 ±6% or 42 dB ±0.5 dB (Ch. 1, .775V sensitivity)
64:1 ±6% or 36 dB ±0.5 dB (Ch. 2, .775V sensitivity)
20:1 ±6% or 26 dB ±0.5 dB (Ch. 1, 26 dB gain)
20:1 ±6% or 26 dB ±0.5 dB (Ch. 2, 26 dB gain)
Required AC Mains 50/60 Hz; 100-, 120-, and 230 - VAC (±10%) units are avail-
able. 230 VAC, 50/60 Hz units can be used with 220 and 240
VAC. Current, voltage and frequency requirements are pro-
vided on the unit’s back panel.
50/60 Hz; 100-, 120-, and 230 - VAC (±10%) units are available. 230
VAC, 50/60 Hz units can be used with 220 and 240 VAC. Current,
voltage and frequency requirements are provided on the unit’s back
panel.
Power Draw at Idle 90 watts or less 90 watts or less
Construction MMMacro-Tech 24X6 MMacro-Tech 36X12
Cooling Internal heat sinks with forced-air cooling
for rapid, uniform heat dissipation
Internal heat sinks with forced-air cooling for
rapid, uniform heat dissipation
Dimensions
Width
Height
Depth (behind mounting surface)
EIA Standard 19-inch rack mount (EIA RS-310-B)
3.5 inch (8.9 cm)
16 inch (40.6 cm)
EIA Standard 19-inch rack mount (EIA RS-310-B)
3.5 inch (8.9 cm)
16 inch (40.6 cm)
Weight
Net
Shipping
Center of gravity is 6 inches (15.2 cm) behind the front mounting surface
45 lb 4 oz (20.5 kg)
54 lb 11 oz (24.8 kg)
50 lb (22.7 kg)
59 lb (26.8 kg)
7 Specifications
