CP660 Power Amplifi er
Operation Manual page 5
Congratulations on your purchase of a
Crown
®
CP660 six-channel power amplifi er.
The CP660 has been designed to give you
super fl exibility and the best watts-to-dollar
ratio around. With six independent channels,
the CP660 takes the place of three, two chan-
nel amplifi ers, yet still fi ts in a standard
two-rack space. Its 75 watts average output
per channel* is ideal for a variety of sur-
round-sound uses, as well as many paging,
zoning, and background music applications.
Plus, when you need it, you can easily bridge
any pair of consecutive channels for double
the power.
In addition, CP660 amplifi er includes a
number of features which require some expla-
nation before they can be used to their maxi-
mum advantage.
Please take the time to study this manual so
that you can obtain the best possible service
from your amplifi er.
* 6 channels into 4-ohm loads.
1.1 Features
• Built for maximum fl exibility, with the best
watts-to-dollars ratio around.
• Six independent amplifi er channels to suit
a wide range of applications.
• Six independent level controls on the back
panel allow convenient level balancing of
all channels.
1 Welcome
2 How to Use This
Manual
This manual provides you with the necessary
information to safely and correctly setup and
operate your
amplifi er. It does not cover
every aspect of installation, setup or operation
that might occur under every condition. For
additional information, please consult Crown’s
Amplifi er Application Guide (available online at
www.crownaudio.com), Crown Tech Support,
your system installer or retailer.
We strongly recommend you read all instruc-
tions, warnings and cautions contained in this
manual. Also, for your protection, please send
in your warranty registration card today. And
save your bill of sale—it’s your offi cial proof
of purchase.
• Three Dual/Mono switches on the back
panel give a broad range of fl exibility in
confi guring your system.
• High-quality, standard-spaced double
banana-jack/binding-post output connec-
tions facilitate any type of speaker connec-
tion, including heavy-gauge wire.
• Super-quiet, variable-speed fan with auto
trigger for silent, effective cooling.
• Compact design is rack-mountable in two
rack spaces (31/2 inches/89 mm).
• The best Three-Year “No-Fault” Fully
Transferable Warranty in the business. It
even covers round-trip ground shipping in
the U.S. for all warranty work.
1.2 Unpacking Your Amplifi er
Please unpack and inspect your amplifi er for
any damage that may have occurred during
transit. If damage is found, notify the trans-
portation company immediately. Only you can
initiate a claim for shipping damage. Crown
will be happy to help as needed. Save the
shipping carton as evidence of damage for the
shipper’s inspection.
We also recommend that you save all packing
materials so you will have them if you ever
need to transport the unit. Never ship the
unit without the factory pack.
1 Channel / 1 Load
4-Ohm
8-Ohm
130W
100W
75W
90W
70W
60W
250W
6 Channels / 3 Loads
4 Channels / 2 Loads
6 Channels / 6 Loads
4 Channels / 4 Loads
*1 kHz Power: refers to maximum average power
in watts at 1 kHz with 0.3% THD.
CP660
*1 kHz Power
Six-Channel Mode
Bridge Mode
2 Channels / 1 Load
200W
150W
