Owner’s manual
English
Owner’s manual
4. NOMENCLATURE
Note:
• Be sure to read this chapter referring to the front diagrams of chapter “3. CONTROLS” on page 5
(unfold).
Names of Buttons
1 PWR (POWER) button
FNC (Function) button
2 SEARCH button
VOLUME button
a button
d button
3 PLAY/PAUSE button
4 Information Panel
5 PS (Preset scan)/AS (Auto store) button
SCN (Scan) button
6 DCP RELEASE lever
7 AF (Alternative Frequencies) button
RPT (Repeat) button
8 PTY (Program Type) button
RDM (Random) button
9 Z-EHCR (Z-enhancer) button
0 INFO (Information) button
TA (Traffic announcement) button
! OPEN button
@ DISP (Display) button
# PRESET buttons (1 to 6)
DIRECT buttons (1 to 6)
$ MUTE button
% BND (Band) button
¥ Color LCD display
& A-M (Audio-Mode) button
* ADJ (Adjust) button
( TITLE button
) NVG (Navigation)/AV button
¡ JOYSTICK
™ Remote Control Infrared Sensor
Note: Be sure to unfold this page and refer to the front diagrams as you read each chapter.
Remarque: Veuillez déplier cette page et vous référer aux schémas quand vous lisez chaque chapitre.
Hinweis: Bitte diese Seite ausfalten und beim Lesen der einzelnen Kapitel die Frontdiagramme beachten.
Nota: Assicurarsi di aprire questa pagina e fare riferimento a questi diagrammi quando si legge ciascun capitolo.
Opmerking:
Vouw deze pagina uit en zie tevens de afbeeldingen van het voorpaneel tijdens het doorlezen van de volgende
hoofdstukken.
Nota: Cuando lea los capítulos, despliegue esta página y consulte los diagramas.
Observera: Vik ut denna sida för att kunna se figurerna över bilstereons framsida medan du läser de olika kapitlen.
Nota: Lembre-se de abrir esta página e consultar os diagramas frontais durante a leiture de cada capítulo.
3.
CONTROLS / COMMANDES / REGLER / CONTROLLI
REGELAARS / CONTROLES / KONTROLLER / CONTROLOS
Main unit / Unité principale / Hauptgerät / Unità principale
Hoofdtoestel / Unidad principal / Huvudenhet / Unidade principale
With the Display closed / Avec l`afficheur fermé / Mit geschlossenem Display /
Con display chiuso / Met het display gesloten / Con el visualisador cerrado /
Med bildskärmen stängd / Com o écran fechado
With the Display open / Avec l`afficheur ouvert / Mit geöffnetem Display /
Con display aperto / Met het display geopend / Con el visualisador abierto
Med bildskärmen öppen / Com o écran aberto
JOYSTICK Operation
With the display closed With the display open
Notes:
• Many settings/procedures have to be performed by using the JOYSTICK
¡
. Be sure to read this
chapter in order to operate it properly.
• In the DVD changer mode, items for menu display, etc. can be selected by operating the JOYSTICK
¡
upward, downward, leftward or rightward.
● Selecting an item in the menu
Select an item displayed in the menu by operating
the JOYSTICK ¡ upward or downward.
● Setting an option for the selected item
When the setting options for an item are listed
on the right of the display, you can choose the
desired option by operating the JOYSTICK ¡
leftward or rightward. Then, press the center of
the JOYSTICK ¡ to set your choice.
● When “push NEXT” is displayed next to
the menu item
1. Press the ENT at the center of the
JOYSTICK ¡ to select the item and show
the setting display for this item.
2. Operate the JOYSTICK ¡ upward or
downward to select the desired setting
option, then press ENT at the center of the
JOYSTICK ¡ to set your choice.
● Returning to the previous mode
Select the item “MENU” by operating the
JOYSTICK ¡ leftward or rightward, then press
the ENT at the center of the JOYSTICK ¡.
4 6 7 8
$% @
9
5
3
1
0
!
#
2
) (¡ *™ &
¥
