INTRODUCTION
The Clarion MCD360 is a full-featured Three-Way Crossover. When used to
build a 2-way system with front and rear fader capability or a full three-way
system, the Clarion MCD360 electronic crossover allows you to choose from a
wide range of crossover points between the front, rear and subwoofer outputs.
The MCD360 includes the following features:
• 6-channel electronic crossover
• Continuously variable crossover frequency with Multiplier Switch
• Separate inputs for front, rear and subwoofer
• Front and rear high-pass outputs
• Non-fade low-pass output
• Adjustable low-pass gain
• Subwoofer Bass Boost
• Remote Subwoofer Level Control
• Ground loop isolation input circuit
• Gold-plated RCA input/output connectors
• Remote turn-on circuit
• Power-on LED
ABOUT THE MANUAL AND WARRANTY
To start enjoying your new Clarion MCD360 Three-Way Crossover, please
read the instructions listed in this manual. Keep all instructions for future
reference. Please fill out and send in the enclosed warranty card to protect
your purchase and aid in warranty service. Also, save your original sales
receipt as proof of purchase.
TABLE OF CONTENTS
Description • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •2
Input/Output Connections and Audio Controls • • • • • • • • • • • • • • •3
Mounting Precautions • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •5
Wiring Precautions • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •6
Applications • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •8
Troubleshooting • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •14
Product Specs • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •15
DESCRIPTION
The Clarion MCD360 has the ability to accept one, two or three sets of RCA
cables as an input.
Both the front and rear outputs of the MCD360 make use of a built-in 18dB per
octave electronic crossover that is continuously variable from 32Hz to 8kHz.
The subwoofer output also uses an 18dB electronic crossover, and it is
adjustable from 45Hz to 250Hz.
The dash mounted bass level control provides a convenient way to adjust the
bass to suit your taste without having to leave your seat.
2
