Contents
1. FEATURES ..................................................................................................................................... 2
2. PRECAUTIONS .............................................................................................................................. 3
Handling Compact Discs................................................................................................................. 4
Flip Down Panel .............................................................................................................................. 4
3. CONTROLS .................................................................................................................................... 5
4. NOMENCLATURE .......................................................................................................................... 6
Names of Buttons............................................................................................................................ 6
Display Items................................................................................................................................... 6
5. DCP ................................................................................................................................................. 7
6. REMOTE CONTROL ...................................................................................................................... 8
Inserting the Batteries ..................................................................................................................... 8
Functions of Remote Control Unit Buttons ..................................................................................... 9
7. OPERATIONS ............................................................................................................................... 10
Basic Operations........................................................................................................................... 10
Radio Operations .......................................................................................................................... 12
CD Operations .............................................................................................................................. 14
Other Handy Functions ................................................................................................................. 15
8. OPERATIONS OF ACCESSORIES ............................................................................................. 17
CD Changer Operations ............................................................................................................... 17
MD Changer Operations ............................................................................................................... 19
TV Operations ............................................................................................................................... 20
9. TROUBLESHOOTING.................................................................................................................. 22
10. ERROR DISPLAYS....................................................................................................................... 23
11. SPECIFICATIONS ........................................................................................................................ 24
Thank you for purchasing this Clarion product.
∗ Please read this owner’s manual in its entirety before operating this equipment.
∗ After reading this manual, be sure to keep it in a handy place (e.g., glove compartment).
∗ Check the contents of the enclosed warranty card and keep it carefully with this manual.
∗ This manual includes the operating procedures of the CD changer, MD changer and TV tuner con-
nected via the CeNET cable. The CD changer, MD changer and TV tuner have their own manuals,
but no explanations for operating them are described.
1. FEATURES
■ Rotary Encoder Volume Control with Illuminated Search Key
■ Touch-n-GO Flip Down Detachable Face
■ Controller for Optional TV Tuner Module
■ Capability to Read CD TEXT Data from Clarion Compatible CD Changer
■ Z-Enhancer with 3 Adjustment Modes
■ CeNET with Balanced Audio Line Transmission and Dynamic Noise Canceling
■
®
FM Reception System
■ 8-Times Oversampling Digital Filter and Dual 1-Bit D/A Converters
■ Zero-Bit Detector™ Mute Circuit
■ 4V/4-Channel RCA Line Level Output with Fader Control
■ 4V/2-Channel Non-Fade RCA Line Level Output
■ 180W (45W × 4) Maximum Power Output
11. ESPECIFICACIONES
Sintonizador de FM
Gama de frecuencias:
87,9 a 107,9 MHz
Sensibilidad útil:
11 dBf
Sensibilidad a 50 dB de silenciamiento:
17 dBf
Selectividad de canal alternativo:
75 dB
Separación entre canales (1 kHz):
35 dB
Respuesta en frecuencia (±3 dB):
30 Hz a 15 kHz
Sintonizador de AM
Gama de frecuencias:
530 a 1710 kHz
Sensibilidad útil:
25
µ
V
Reproductor de discos compactos
Sistema:
Sistema audiodigital de discos compactos
Discos utilizables:
Discos compactos
Respuesta en frecuencia (±1 dB):
5 Hz a 20 kHz
Relación señal-ruido (1 kHz):
100 dB
Gama dinámica (1 kHz):
95 dB
Distorsión armónica:
0,01%
Audio
Salida máxima de potencia:
180 W (45 W × 4 canales) (EIAJ)
Salida media continua de potencia:
17 W × 4, con 4 Ω, de 20 Hz a 20 kHz, 1% de
distorsión armónica total
Acción de control de graves (30 Hz):
±13 dB
Acción de control de agudos (10 kHz):
±10 dB
Salida de línea (reproductor de discos compactos 1 kHz):
4 V
Generales
Tensión de alimentación:
14,4 V CC (permisible de 10,8 a 15,6 V),
negativo a masa
Consumo de corriente:
Menos de 15 A
Impedancia de los altavoces:
4 Ω (permisible de 4 a 8 Ω)
Peso / Unidad fuente:
3,75 lb. (1,7 kg)
Peso / Controlador remoto:
1 oz. (30 g) (incluyendo la pila)
Dimensiones / Unidad fuente:
7
"
(An) × 2
"
(Al) × 6-1/8
"
(Prf)
[178 (An) × 50 (Al) × 155 (Prf) mm]
Dimensiones / Controlador remoto:
1-3/4
"
(An) × 4-5/16
"
(Al) × 1-1/8
"
(Prf)
[44 (An) × 110 (Al) × 27 (Prf) mm]
Notas:
•
Las especificaciones están de acuerdo con las normas de la EIA.
•
Las especificaciones y el diseño están sujetos a cambio sin previo aviso por motivo de mejoras.
