Clarion DB256 CD Player User Manual



11
English
DB256
CLOCK(E) SCRN SVR
Basic Operations
Illumination dimmer function
When the illumination line of this unit is connected
with the car-side illumination signal line, the dis-
play illumination of this unit dims in connection
with turning on the car-side illumination.
Turning on/off MAGNA BASS EX
The MAGNA BASS EX does not adjust the low
sound area like the normal sound adjustment func-
tion, but emphasizes the deep bass sound area
to provide you with a dynamic sound.
The factory default setting is off.
Press and hold the
[
A-M
]
button for 1 second or
longer to turn the MAGNA BASS EX and “M-B EX
in the display lights on or off.
ADJ mode adjustment
1. Press
[
D
]
button more than 1 second at POWER
ON mode to enter ADJ mode, the previous se-
lected ADJ items will be called out.
2. Press
[
D
]
button again at ADJ mode will cancel
ADJ mode and return to previous display.
3. Press
[
SRC
]
button will also release ADJ mode.
4. ADJ mode will also be released when current
source mode is changed. (Mode changes of
LOADING, EJECT, interruption and interrup-
tion release)
5. Press
[ ]
/
[ ]
button to switch the ADJ mode
items,
6. The ADJ Mode Title will be display for 2 sec-
onds before showing the ADJ Mode setting.
Adjusting clock setting
1. Press the
[
D
]
button and press
[ ]
/
[ ]
button
to select "CLOCK (E)".
2. Press [ ] button to start clock adjustment,
the HOUR is selected and blinking by default.
3. Press
[ ]
/
[ ]
button to toggle HOUR and
MINUTE selection.
4.Turn the
[
ROTARY
]
knob clockwise to in-
creases hour/minute or counterclockwise to
decrease hour/minute.
5. Press
[ ]
button to confirm the clock setting,
the clock will blink for 2 seconds and return to
"CLOCK(E)".
Note:
If you remove the vehicle's battery for a check or
repair, the clock will be reset, so you must set it
again.
Adjusting the balance
1. Press the
[
A-M
]
button and select “BAL”.
2. Turning the
[
ROTARY
]
knob clockwise empha-
sizes the sound from the right speaker; turn-
ing it counterclockwise emphasizes the sound
from the left speaker.
The factory default setting is “0”.
(
Adjustment
range: L13 to R13
)
Adjusting screensaver setting
1. Press the
[
D
]
button and press
[ ]
/
[ ]
button
to select "SCRN SVR".
2. "SS ON" or "SS OFF" will be display after 2
seconds.
3. Turn the
[
ROTARY
]
knob clockwise to turn on
the screensaver or counterclockwise to turn off
the screensaver.
4. If Screensaver setting is set to on, Screensaver
will be activated after 30 seconds of no key op-
eration.
Adjusting the fader
1. Press the
[
A-M
]
button and select “FAD”.
2. Turning the
[
ROTARY
]
knob clockwise empha-
sizes the sound from the front speakers; turn-
ing it counterclockwise emphasizes the sound
from the rear speakers.
The factory default setting is “0”. (Adjustment
range: F12 to R12)
Note:
Bass and Treble can only be adjusted when the “Z-
enhancer” is off.
Switching display
Press and hold the
[
BND
]
button, and then press
the
[
DISP
]
button to select the desired display.
The display switches in the following order:
Main Display
ÆÆ
ÆÆ
Æ Clock Display
ÆÆ
ÆÆ
Æ Main Display …
If the display is changed by other button operation
when the clock is displayed, the clock display re-
turns automatically after the operation.
