Setting the Z-enhancer
This unit comes with three types of sound tone
effects stored in memory. Select the one you prefer.
*
The factory default setting is “Z-EHCR OFF”.
Each time you press [Z-EHCR] button, the tone
effect changes in the following order.
“Z-ENHANCER 1” ➜ “Z-ENHANCER 2” ➜
“Z-ENHANCER 3” ➜ “Z-EHCR OFF” ➜
“Z-ENHANCER 1”...
• Z-ENHANCER 1: bass emphasized
• Z-ENHANCER 2: treble emphasized
• Z-ENHANCER 3: bass and treble emphasized
• Z-EHCR OFF: no sound effect
Switching the Clock Display
Press and hold the [BND] button, and then press
the [DISP] button to switch between the opera-
tion mode and the clock display.
Setting the Clock
1) Press and hold the [BND] button, and then
press the [DISP] button to display the clock
display.
2) Press and hold the [
BND] button, and then
press the [DISP] button for 2 seconds or
longer.
3) Press the [
d] button, then set the current
minute.
4) Press the [
a] button, then set the current
hour.
5) Press the [
BND] button, then the clock is set.
Notes:
•
If you select another operation mode while you are
setting the clock, the clock setting operation will be
canceled.
•
If you remove the vehicle’s battery for a check or
repair, the clock will be reset, so you must set it again.
Screen Saver mode
1) Press and hold the [BND] button, and then
press the [
SS] button to switch on, and off
Screen saver mode
*
The factory default setting is “SS On”.
Radio Mode Operations
FM Reception
For enhanced FM performance the
®
tuner includes signal actuated stereo control and
Multipath noise reduction circuits.
Listening to the Radio
1) Press the [FNC] button to select the radio
mode, then the radio will be on.
2) To select a preset band, press the [
BND] but-
ton, then select one of the preset bands such
as FM1, FM2, FM3, or AM. Every time the
[BND] button is pressed, the display will
change as:
FM1 ➜ FM2 ➜ FM3 ➜ AM ➜ FM1
3) Press the [
a][d] button, then the station at
which there is a broadcast will be selected
(Seek selection).
Manual Tuning
1) Press the [BND] button, then select FM1,
FM2, FM3 or AM.
2) Press and hold the [
BND] button for 1 second
or longer, then the display will show “MANU”,
which means that a manual selection func-
tion is on.
3) Press the [
a][d] button and select the right
station.
Seek Tuning
1) Press the [BND] button, then select FM1,
FM2, FM3 or AM.
2) If the “
MANU” on the display is on, press and
hold the [BND] button for 1 second or longer.
When the “MANU” display is off, the seek
selection function is on.
3) Press the [
a][d] button, then when it
selects the station in which there is a broad-
cast, it automatically stops.
DB335/DB235 11
English
