ENGLISH
17
En
LISTENING TO EXTERNAL
SOURCES
To play equipment connected to the VIDEO/AUX/PHONO IN
jacks, proceed as follows.
1
Press VIDEO/AUX/PHONO.
“VIDEO” appears on the display.
2
Play the connected equipment.
To change a source name on the display
When VIDEO/AUX/PHONO is pressed, “VIDEO” is displayed
initially. It can be changed to “AUX”, “TV” or “PHONO”.
With the power on, press POWER while pressing VIDEO/AUX/
PHONO.
Repeat the procedure to select one of the names.
NOTE
• During recording, the sound level cannot be adjusted.
OTHER CONNECTIONS
CONNECTING OPTIONAL
EQUIPMENT
Refer to the operating instructions of the connected equipment
for details.
• The connecting cords are not supplied. Obtain the necessary
connecting cords.
• Consult your local Aiwa dealer for optional equipment.
VIDEO/AUX/PHONO IN JACKS
This unit can input analog sound signals through these jacks.
Use a cable with RCA phono plugs to connect audio equipment
(LD player, MD player, VCR, TV, etc.).
Connect the red plug to VIDEO/AUX/PHONO IN R jack, and the
white plug to VIDEO/AUX/PHONO IN L jack.
When connecting a turntable
Use an AIWA turntable equipped with a built-in equalizer amplifier.
CLOCK AND TIMER
OTHER CONNECTIONS
VIDEO/
AUX/
PHONO
VOLUME
POWER
