2-4 User’s Manual
The Grand Tour
Left side
The following figure shows the computer’s left side.
The left side of the computer
PC Card Slot
ExpressCard Slot
i .LINK (IEEE1394) PortUniversal Serial Bus
(USB) Port
Cooling Vents
Universal Serial Bus
(USB) Port
The Universal Serial Bus (USB 2.0 and 1.1) port
enables USB-equipped devices (such as
keyboards, mice, hard drives, scanners, and
printers) to be connected to the computer.
Cooling Vents The cooling vents helps to keep the inside from
overheating.
i .LINK (IEEE1394)
Port
Connect an external device, such as a digital
video camera to this port for high-speed data
transfer. This only applies the i.LINK model of the
computer.
PC Card Slot The PC Card slot can accommodate one Type II
PC Card. You can install any industry standard
PC Card such as a SCSI adapter, Ethernet
adapter or flash memory card.
ExpressCard Slot This slot allows you to insert an ExpressCard. An
ExpressCard module is a small, modular add-in
card technology based on PCI Express and
Universal Serial Bus (USB) interface. Both
ExpressCard/34 and ExpressCard/54 are
supported.
This feature may not be present, depending on
your configuration.
