18
PAL System
Possible Recording Time HDD=80 Gigabytes
Refresh Rate (Field/Sec) 50 25 12.5 6.25 3.13 1.56 0.89 0.31 0.21 0.16
HIGH 14 hr 28 hr 54 hr 112 hr 224 hr 448 hr 784 hr 2240 hr 3360 hr 4480 hr
STANDARD 22 hr 44 hr 88 hr 176 hr 352 hr 704 hr 1232 hr 3520 hr 5280 hr 7040 hr
Quality
BASIC 28 hr 56 hr 112 hr 224 hr 448 hr 896 hr 1568 hr 4480 hr 6720 hr 8960 hr
REC Time Mode 3 hr 6 hr 12 hr 24 hr 48 hr 96 hr 168 hr 480 hr 720 hr 960 hr
REC interval (1/50 sec) 1 2 4 8 17 32 57 161 241 321
4.2 Recording Operations
This section details the way to record video into hard-disk drives. Before commencing with the
recording function, please configure the recording setting properly according to your needs.
4.2.1 Manual Recording
When the unit is in the live display mode, take the following steps to start recording:
(1) In live display, press the REC button
to record video onto a hard disk drive with the
corresponding programmed recording settings. The monitor should display a flashing REC message
and the REC button will light up indicating the unit is in the recording status.
(2) Press the
STOP button to stop recording any time.
(3) To access just recorded video, please refer to section 4.4 for more details.
