– 64 –
APPENDIX
Appendix A: Specifications
A-1. General Specifications
Printing system ......................... Line thermal dot-matrix
Resolution .................................8 dots/mm (horiz.) × 8 dots/mm (vert.)
Printable width.......................... Page Mode 80 mm
Line Mode 75 mm
Printing speeds..........................640 dots line/sec (Max. 80 mm/sec.)
Interfaces ..................................RS-232C, Bidirectional paral
Weight ......................................TSP412Z: 3.4 kg
TSP442Z: 3.7 kg
Power ........................................ (50/60Hz) AC120V, AC230V
Power consumption ..................Operating: Approx. 30W (During continuous
printing of ASCII characters)
Stand-by: Approx. 8W
Operating environment ............. +5 ~ +40 °C
25 ~ 85 % RH
Storage environment................. –20 ~ +60 °C
10 ~ 90 % RH
Automatic paper cutter
Life ....................................... 300, 000 cuts (if paper debris is cleared)
Min. cut length ..................... 25.4mm (1 inch)
178 mm
226 mm
256 mm
(TSP412Z) (TSP442Z)
