Location and function of controls
Main unit
XNV-L77BT/770BT
Refer to the pages listed for details.
A Disc slot (located behind the front panel)
page 21
B VOL (Volume) –/+* buttons
C Receptor for the card remote
commander
D Display window/touch panel
E Reset button page 17
F (Bluetooth) signal indicator
page 40
G TOP button
To open the top menu.
H SOURCE/OFF button
Press to turn on the power/change the source:
“Tuner” (Radio), “Disc,” “AUX” (Auxiliary
equipment), “USB/iPod,” “BT Audio”
(Bluetooth Audio).
Press for 1 second to turn off the power.
Press for more than 2 seconds to shut off
completely.
I Z (Open/Close) button page 21
* The VOL + button has a tactile dot.
VOL
TOP
OFFSOURCE
1
2 3 4 5
6 7 8 9
