14
English
Display Format
VGA
VESA
640x480
at 85 Hz
MAC
832x624
at 75 Hz
VESA
800x600
at 85 Hz
MAC
1152x864
at 75Hz
VESA
1024x768
at 75 Hz
VESA
1024x768
at 85 Hz
1024x768
at 100Hz
VESA
1280x1024
at 75 Hz
VESA
1280x1024
at 85 Hz
VESA
1600x1200
at 75 Hz
VESA
1600x1200
at 85 Hz
Hotizontal Dots 640 720 640 832 800 1152 1024 1024 1024 1280 1280 1600 1600
Vertical Lines 480 400 480 624 600 864 768 768 768 1024 1024 1200 1200
H. Frequency(kHz) 31.469 43.269 49.726 53.674 67.500 60.024 68.677 80.468 79.976 91.146 93.750 106.962
H. Sync. Polarity OFF-LOW + + + + + + + +
Aµs (Period) 31.778 23.111 20.110 18.631 14.815 16.660 14.561 12.427 12.504 10.971 10.667 9.349
*Bµs (Pulse Width) 3.813 1.556 1.117 1.138 1.185 1.219 1.016 1.073 1.067 1.016 0.948 0.962
Cµs (Back Porch) 1.907 2.222 3.910 2.702 2.370 2.235 2.201 1.945 1.837 1.422 1.501 1.237
Dµs (Active Area) 25.422 17.778 14.524 14.222 10.667 13.003 10.836 9.309 9.481 8.127 7.901 6.874
Eµs (Front Porch) 0.636 1.555 0.559 0.569 0.593 0.203 0.508 0.100 0.119 0.406 0.316 0.275
V. Frequency(Hz) 59.940 70.087 85.008 74.552 85.062 75.000 75.030 84.997 99.836 75.024 85.024 75.000 85.026
V. Sync. Polarity + OFF-LOW + + + + + + + +
Oms (Period) 16.683 14.268 11.763 13.413 11.756 13.333 13.328 11.765 10.016 13.329 11.761 13.333 11.761
Pms (Pulse Width) 0.064 0.069 0.060 0.056 0.044 0.050 0.044 0.037 0.038 0.033 0.032 0.028
Qms (Back Porch) 1.049 1.112 0.578 0.784 0.503 0.474 0.466 0.524 0.423 0.475 0.483 0.491 0.505
Rms (Active Area) 15.253 12.711 11.093 12.549 11.179 12.800 12.795 11.183 9.544 12.804 11.234 12.800 11.219
Sms (Front Porch) 0.318 0.381 0.023 0.020 0.018 0.015 0.017 0.014 0.012 0.012 0.011 0.011 0.009
Pixel Rate (MHz) 25.175 28.322 36.000 57.284 56.250 108.000 78.751 94.500 110.000 135.000 157.500 202.500 232.750
TECHNICAL INFORMATION
HORIZONTAL
Preset Timing Chart
Note:This monitor is equipped with a micro-processor which allows the user
to set his own preferred mode(s) beyond those standard mode listed
below.
VERTICAL
* Bµs (Pulse Width) should be more than 0.5 µs.
To reduce visual tiredness and eye strain, it is recommended to choose the highest refresh modes available.
