This manual describes the procedure for controling the HSR-1/1P Digital
Surveillance Recorder using the RS-232C from an external computer, etc.
The RS-232C is the EIA standard for the interface of the communication via a
modem between data terminal equipment. In this interface, data are transferred
serially bit by bit. Since the RS-232C interface is employed in most computers
as a standard interface, it can be used in a wide range of applications.
Table of Contents
Overview ............................................................................................... 3
Signal Connections ........................................................................................3
Data Format ...................................................................................................3
Command Table.............................................................................................3
Communication Protocol .................................................................... 4
Detailed Descriptions of Commands ................................................. 5
VTR Return Commands ................................................................................5
Numerical Value Commands.........................................................................5
General Purpose Control Commands ............................................................6
Mode Control Commands..............................................................................6
Status Request Commands ..........................................................................10
Tape Run System Commands......................................................................16
Menu ITEM Numbers and Set Values.........................................................18
Purpose of This Manual
