11
TP-400-2146-01-RG-SMA
Drive Controls Group — Gear Models
1 1713843 1 KNOB, Plastic, Gear Shift
2 1714756 1 ROD, Shift
3 156302 1 SPRING, Gear Shift
4 1714385 1 ROD, Parking Brake
5 1713855 1 KNOB, Plastic, Parking Brake
6 1678341 1 SPRING, Return
7 1918447 3 PIN, Cotter, 3/32 x 3/4
8 1919326 1 WASHER, Plain, 5/16
9 1714767 1 ROD, Brake
10 157041 1 SPRING, Brake Rod
11 1919438 5 NUT, Hex Nylon Lock, 5/16-18
12 1919326 2 WASHER, Plain, 5/16
13 1663114 2 BUSHING, 5/8
14 1931353 1 CARRIAGE BOLT, 3/8-16 x 1-3/4
15 165068 2 SPRING, Idler
16 1717438 1 BRACKET, Idler
17 1707289 1 PULLEY, Backside
18 1928352 1 NUT, Hex Flange Whiz Lock, 3/8-16
19 1924940 1 WASHER, Plain, 3/8
20 1916965 1 LOCKWASHER, 3/8
21 1921971 1 CAPSCREW, Hex Hd, 3/8-16 x 1-3/4
22 1708352 1 GUARD
23 1714526 1 PULLEY, Idler, V
24 1713784 1 CLAMP, Tube
25 1931333 4 CARRIAGE BOLT, 5/16-18 x 3/4
26 1717994 1 FOOT PEDAL ASSEMBLY
27 1714773 1 PAD, Brake Pedal
28 1717439 1 LEVER, Parking Brake
29 1713785 1 GUIDE, Brake Rod
30 1713432 1 ROD, Clutch
31 1918448 2 PIN, Cotter, 3/32 x 1
32 1921319 1 WASHER, Plain, 1/4
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
*See your local Tecumseh/Peerless distributor for transaxle service parts.
(See pages 12-15 for service parts listing.)
The above parts group applies to the following Mfg. Nos.:
1693074 Regent 14HP Gear
1693076 Regent 14HP Gear-Export
1693084 Regent 16HP Gear
1693086 Regent 16HP Gear-Export
1693092 514G, 14HP Gear
1693100 2514G, 14HP Gear
1693323 Regent 14HP Gear
1693331 Regent 14HP Gear-Export
1693339 514G, 14HP Gear
1693345 2514G, 14HP Gear
