■ NETWORK SETUP
On the ADMINISTRATOR SETUP PAGE click the NETWORK button to display the NETWORK SETUP window.
Select LAN/PPP, and set IP address, netmask, and default gateway.
q IP ADDRESS (LAN)
Enter the IP address to be used with LAN.
The factory default setting is 192.168.0.10.
w NETMASK (LAN)
Enter the netmask to be used with LAN.
The factory default setting is 255.255.255.0.
e DEFAULT GATEWAY (LAN)
Enter the default gateway to be used with LAN.
The factory default setting is 192.168.0.1.
r IP ADDRESS (PPP)
Enter the IP address to be used with PPP.
The factory default setting is 192.168.1.10.
t NETMASK (PPP)
Enter the netmask to be used with PPP.
The factory default setting is 255.255.255.0.
y DEFAULT GATEWAY (PPP)
Enter the default gateway to be used with PPP.
The factory default setting is 192.168.1.1.
u REMOTE IP ADDRESS
Used when PPP mode is on P to P ACCESS.
Enter the IP address of the PC which calls and access-
es the WJ-NT104. The PC's IP address must be set to
Obtain an IP automatically. The factory default setting
is 192. 168. 1.11.
i PPP MODE
• P to P ACCESS mode
To use this mode, match the IP address of the PC
with the address of the WJ-NT104.
• NETWORK ACCESS mode
To use this mode, match the address of the WJ-
NT104 with the address of the PC. (Independent of
outgoing and incoming calls)
The factory default setting is P to P ACCESS.
o HOSTNAME
Enter the host name.
Alarm notice (e-mail) is sent in the host name specified
here. The host name you enter may be different from
that entered for the domain settings (DNS).
The factory default setting is WJ-NT104.
!0 NETWORK TYPE
Select LAN or PPP.
If PPP is marked, access via LAN is not possible.
q
w
e
r
t
y
u
i
o
!0
