1.1 General Features
70 Feature Manual
In this example
When a visitor presses the Call button of Doorphone 2:
– A doorbell/door chime, connected to Relay 4, chimes with Pattern 2.
– Because Doorphone Ring/Chime is set to "Chime", extension 101 does not ring.
– The extension user who is allowed to receive a call from Doorphone 2 can answer the doorphone
call by going off-hook within a preprogrammed time period ( [708] Doorphone Ring Time). If the
user is allowed to unlock the door ( [703-705] Door Opener—Day/Night/Lunch), he or she can
then unlock the door by entering the Door Open feature number.
– If the called extension is busy and has set Call Waiting, the extension user hears a call waiting tone
and the call information flashes on the display.
Conditions
• Hardware Requirement: A user-supplied doorbell/door chime connected to each door opener.
Installation Manual References
2.7 Connecting Doorbell or Door Chime
Programming Manual References
[PT Programming]
[700-702] Doorphone Ringing—Day/Night/Lunch
[703-705] Door Opener—Day/Night/Lunch
[708] Doorphone Ring Time
[710] Doorphone Ring/Chime
[711] Doorphone Chime Assignment
[712] Doorphone Chime Pattern
[PC Programming]
9.7.1 Ringing & Door Opener [7-1]
Programming Doorphone
1 2 3 4
Doorphone Ringing*
1
Enable (extn.
101)
Enable (extn.
101)
Enable (extn.
101)
Enable (extn.
101)
Doorphone Ring/Chime*
2
Chime Chime Chime Chime
Doorphone Chime
Assignment*
3
Relay 4 Relay 4 Relay 4 Relay 4
Doorphone Chime Pattern*
4
Pattern 1 Pattern 2 Pattern 3 Pattern 4
*
1
[700-702] Doorphone Ringing—Day/Night/Lunch
*
2
[710] Doorphone Ring/Chime
*
3
[711] Doorphone Chime Assignment
*
4
[712] Doorphone Chime Pattern
