QoS Settings
VLAN ID
Description Available Settings Default Setting
Determines the VLAN ID.
• If this setting is changed, the unit must be restarted
before the new setting becomes effective (see page 43).
0001–4095
4095
VLAN Priority
Description
Available Settings Default Setting
Determines the VLAN priority.
• If this setting is changed, the unit must be restarted
before the new setting becomes effective (see page 43).
0–7 0
SIP ToS Field
Description
Available Settings Default Setting
Determines the value of the SIP ToS Field.
• If this setting is changed, the unit must be restarted
before the new setting becomes effective (see page 43).
8-bit binary code
00000000
RTP ToS Field
Description
Available Settings Default Setting
Determines the value of the RTP ToS Field.
• If this setting is changed, the unit must be restarted
before the new setting becomes effective (see page 43).
8-bit binary code
00000000
Document Version 2008/10 Operating Instructions 53
Programming the Unit
