Remote Controller—Continued
Dock mode is for controlling an Apple iPod in an Onkyo
RI Dock.
When Using an RI Dock:
• Connect the RI Dock to the TAPE IN or GAME/TV
IN L/R jacks.
• Set the RI Dock’s RI MODE switch to HDD or
HDD/DOCK.
• Set the AV receiver/AV amplifier’s Input Display to
DOCK (see page 50).
• When operating a DS-A1 RI Dock, enter the appropri-
ate remote control code for the first time (see
page 104).
• See to the RI Dock’s instruction manual for more
information.
To set the remote controller to DOCK mode, press
the [DOCK] REMOTE MODE button.
STANDBY button
Turns off the iPod.
ON button*
Turns on the iPod.
TOP MENU button
Works as a Mode button when used with a DS-A2
RI Dock.
Arrow [ ]/[ ] and ENTER buttons*
Used to navigate menus and select items.
ALBUM +/– button*
Selects the next or previous album.
DISPLAY button*
Turns on the backlight for 30 seconds.
Previous [ ] button
Restarts the current song. Press it twice to select the
previous song.
Pause [ ] button
Pauses playback. (With 3rd generation iPods, it
works as a Play/Pause button.)
Rewind [ ] button
Press and hold to rewind.
(1 Playlist [ ]/[ ] buttons*
Used to select the previous or next playlist on the
iPod.
(2 REPEAT button*
Used with the repeat function.
(3 MENU button*
Used to access menus.
(4 Play [ ] button
Starts playback. If the component is off, it will turn
on automatically. (With 3rd generation iPods, this
button works as a Play/Pause button.)
(5 Next [ ] button
Selects the next song.
(6 Stop [ ] button
Stops playback and displays a menu.
(7 Fast Forward [ ] button
Press and hold to fast forward.
(8 RANDOM button*
Used with the shuffle function.
(9 PLAY MODE button
Used to select play modes on components with
selectable play modes.
Works as a Resume button when used with a DS-A2
RI Dock.
* Buttons marked with an asterisk (*) are not supported
by 3rd generation iPods.
DOCK Mode
6
7
8
9
2
bl
br
bo
bm
bs
bq
1
3
5
bn
bp
bk
4
