54
Chapter 3: The Dual-Band
Wireless A+G Notebook Adapter’s
LEDs
The Adapter has two LEDs to let you know how the card is functioning. Here
is a description of those LEDs:
Power Green. The Power LED lights up when the Adapter is pow-
ered on.
Link Green. The Link LED lights up and stays solid when the
Adapter is inserted correctly and a link is established with
the notebook. The LED flashes when data is transmitted or
received.
Chapter 4: Installation and
Configuration for Windows XP
After installing the Dual-Band Wireless A+G Notebook Adapter in your com-
puter, you will install the driver and configure the Adapter.
1. Turn off your notebook PC.
2. Locate an available CardBus slot on your notebook PC.
3. With the Adapter’s
label facing up, as
shown in Figure 4-1,
slide it completely
into the CardBus
slot.
4. Restart your note-
book PC.
5. Windows will begin copying the driver files to your computer. If Windows
asks you for the original Windows CD-ROM, insert the CD-ROM, and
direct Windows to its proper location (e.g., D:\).
Proceed to the next section, “Driver Installation for Windows XP.”
Important for Windows 98, Me, and 2000 users: Go to “Chapter 5:
Installation and Configuration for Windows 98, Me, and 2000.”
Figure 4-1
Overview
Hardware Installation
