27
Network Settings
Setting the IP address for VN-X35U
There are two methods to set the IP address for
VN-X35U as follows.
(A) Assigning an IP address to VN-X35U from
the DHCP server
(B) Assigning a static IP address to VN-X35U
Ⅵ (A) Assigning an IP address from the
DHCP server
● VN-X35U is set to ADHCP EnableB (the
DHCP client feature is on) by default. To
assign an IP address from the DHCP server,
connect VN-X35U to LAN with DHCP server,
and turn on VN-X35U. Allowing the DHCP
server to assign the same IP address to
VN-X35U every time eases access to
VN-X35U.
● For details on IP addresses assigned to
VN-X35U
, consult your network
administrator.
● You can look up the IP address of VN-X35U
using the search tool in the ATOOL_EB folder
in the supplied CD-ROM.
For details, please refer to the AReadmeB file
in the ATOOL_EB folder.
You can look up the IP address of VN-X35U
using the search tool in the supplied
CD-ROM.
For details, please refer to AReadmeB file in
the CD-ROM.
Note:
● Set the DHCP server such that the same IP
address is always assigned to the MAC
address of
VN-X35U
by the DHCP server.
Connection may fail if the above setting is not
performed.
Ⅵ (B) Assigning a static IP address
ⅷ System configuration required for setting
IP address
The default setting for VN-X35U is ADHCP
EnableB (DHCP client feature is turned on).
Upon starting up in LAN without DHCP server,
VN-X35U starts running with the following IP
address after time out of DHCP.
IP address : 192.168.0.2
Subnet mask : 255.255.255.0
Default gateway : Nil
Memo:
● To set a static IP address for VN-X35U,
connect VN-X35U, the switching hub and the
computer for setting using a straight LAN
cable of Category 5 and above.
ⅷ Set up the computer for setting the IP
address.
● Minimum computer specifications for
setting
OS : Windows XP (Professional or
Home Edition) (SP2)
: WindowsVista
Business(SP1)
Web browser : Internet Explorer
XP : Version 6.0
Vista :Version 7.0
Note:
● When setting the IP address for VN-X35U, do
so by using a network that is made up only of
VN-X35U, the computer for setting and the
switching hub.
● Using a hub connected to other network
devices or networks via a LAN cable for
setting can cause problems.
IP Address Settings
