Controls
1 OPEN/EJECT Switch ............................ ੬ pg. 12
2 • Stop Button [5] .................................... ੬ pg. 21
• BACKLIGHT Button .............................
੬ pg. 42
3 • Rewind Button [
2
] ............................. ੬ pg. 21
• NIGHT Button ......................................
੬ pg. 36
4 Play/Pause Button [
4
/6] ....................... ੬ pg. 21
5 Fast-Forward Button [
3
] ..................... ੬ pg. 21
6 Monitor Open Button [PUSH OPEN] ..... ੬ pg. 16
7 Diopter Adjustment Control.................... ੬ pg. 10
8 Battery Release Button
[BATT. RELEASE] ...................................
੬ pg. 8
9 Recording Start/Stop Button .................. ੬ pg. 16
0 • MENU Wheel [+, –, PUSH].................. ੬ pg. 44
• LCD Monitor BRIGHT (Brightness)
Control [+, –] ........................................
੬ pg. 16
! Snapshot Button
[SNAPSHOT] .......................
੬ pg. 26, 27, 40, 52
@ • Power Zoom Lever [T/W]..................... ੬ pg. 18
• Speaker Volume Control [VOL.] ..........
੬ pg. 21
# • FOCUS Button..................................... ੬ pg. 41
• BLANK Button .....................................
੬ pg. 24
$ Lock Button ............................................ ੬ pg. 17
% Power Switch
[
A
U
TO
,
MANUAL
, PLAY, OFF] ................. ੬ pg. 17
^ INDEX Button
(GR-DVL720/DVL520 only) ...................
੬ pg. 29
& INFO Button
(GR-DVL720/DVL520 only) ...................
੬ pg. 29
* VIDEO/MEMORY Switch [VIDEO, MEMORY]
(GR-DVL720/DVL520 only) ...................
੬ pg. 17
( Video Light Switch
[LIGHT OFF/AUTO/ON] .........................
੬ pg. 19
Connectors
The connectors ) to w are located beneath a cover.
) Audio/Video Output Connector
[AV] ............................................
੬ pg. 22, 50, 59
q • J Terminal [JLIP (Joint Level Interface Protocol)]
(GR-DVL320 only) ...............................
੬ pg. 59
You can also connect to a JLIP-compatible
camcorder or VCR to control it from the
computer using the optional Software HS-V16U.
• Edit Connector [EDIT]
(GR-DVL720/DVL520 only) .................
੬ pg. 59
w DC Input Connector ............................. ੬ pg. 8, 9
e Digital Video Connector
[DV IN/OUT] (i.Link*) .......................
੬ pg. 51, 65
* i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The
logo
is used for products compliant with the i.Link
standard.
r S-Video Output Connector
[S-VIDEO] ..................................
੬ pg. 22, 50, 59
t • PC Connector (GR-DVL320 only) ....... ੬ pg. 65
• USB (Universal Serial Bus) Connector
(GR-DVL720/DVL520 only) .................
੬ pg. 65
Indicators
y Tally Lamp ....................................... ੬ pg. 16, 46
u CHARGE Lamp ....................................... ੬ pg. 8
i Power Lamp .................................... ੬ pg. 16, 17
Other Parts
o • Remote Sensor.................................... ੬ pg. 53
• Camera Sensor
Be careful not to cover this area, a sensor
necessary for shooting is built-in here.
p Viewfinder .............................................. ੬ pg. 10
Q Video Light ............................................. ੬ pg. 19
W Stereo Microphone ................................ ੬ pg. 63
E Viewfinder Cleaning Hatch .................... ੬ pg. 74
R Shoulder Strap Eyelets .......................... ੬ pg. 10
T Grip Strap .............................................. ੬ pg. 10
Y LCD Monitor .................................... ੬ pg. 16, 17
U Speaker ................................................. ੬ pg. 21
I Battery Pack Mount ................................. ੬ pg. 8
O Stud Hole ............................................... ੬ pg. 10
P Tripod Mounting Socket ......................... ੬ pg. 10
a MEMORY CARD Cover
(GR-DVL720/DVL520 only) ...................
੬ pg. 14
