EN 49
Controls
1 Power Zoom Button ........................... ੬ pg. 14
2 Select Dial ......................................... ੬ pg. 18
3 Multi-Function Control
•EFFECT Button ................................. ੬ pg. 20
•WIDE Button ...................................
੬ pg. 20
•TITLE Button ....................................
੬ pg. 21
•SUPER LOLUX Button .....................
੬ pg. 21
4 PUSH Button...................................... ੬ pg. 9
5 DATE/TIME Button ............................. ੬ pg. 17
COUNTER R/M Button .......................
੬ pg. 34
6 5SEC. REC [5-sec recording] Button ... ੬ pg. 15
7 REW Button ....................................... ੬ pg. 32
RETAKE R [Quick Review] Button ......
੬ pg. 15
8 PLAY/PAUSE Button ........................... ੬ pg. 32
9 FF Button ........................................... ੬ pg. 32
RETAKE F Button ................................ ੬ pg. 15
0 STOP Button ...................................... ੬ pg. 32
! EJECT Switch ...................................... ੬ pg. 9
@ Function Navigator Dial
[MENU Jog Dial] ................................ ੬ pg. 7
# LIGHT OFF/AUTO/ON Switch
(GR-AX480 only) ................................ ੬ pg. 16
$ BATT. [Battery] RELEASE Switch ......... ੬ pg. 4
% Dioptre Adjustment............................ ੬ pg. 10
^ Recording Start/Stop Button................ ੬ pg. 12
& Power Switch ................................ ੬ pg.12, 32
* LENS COVER Switch.......................... ੬ pg. 12
Connectors
( DC IN Jack ......................................... ੬ pg. 5
The jacks ) to e are located beneath the jack
cover.
) J terminal [JLIP (Joint Level Interface Protocol)
Connector]
•Connect the editing cable when performing
Random Assemble Editing (GR-AX480 only)
(੬ pg. 40 – 43).
•It is used to connect the camcorder to a device
such as a personal computer.
For further detail consult your nearest JVC
dealer.
•JLIP-controlled editing from camcorder to VCR
is not possible if the VCR is not equipped with
a J terminal.
q VIDEO OUT Connector ..................... ੬ pg. 36
w RF DC OUT Connector ...................... ੬ pg. 36
e AUDIO OUT Connector .................... ੬ pg. 36
Indicators
r Power Indicator.................................. ੬ pg. 12
t Tally Lamp (GR-AX480 only).............. ੬ pg. 12
Other Parts
y Video Light (GR-AX480 only) ............. ੬ pg. 16
u Microphone ....................................... ੬ pg. 45
i •Camera sensor
Be careful not to cover this area; built-in
here is the sensor necessary for shooting.
•Remote Sensor (GR-AX480 only) ..... ੬ pg. 39
o Clock Battery Compartment ............... ੬ pg. 6
p Battery Pack Mount ............................ ੬ pg. 4
Q Shoulder Strap Eyelets ........................ ੬ pg. 11
W Electronic Viewfinder ......................... ੬ pg. 10
E Grip Strap .......................................... ੬ pg. 10
R Tripod Mounting Socket ..................... ੬ pg. 11
