70 EN
Controls
1 Diopter Adjustment Control .................੬ pg. 16
2 Lens Cover Open/Close Ring................ ੬ pg. 18
3 Video Light Switch
[LIGHT OFF/AUTO/ON]...................... ੬ pg. 30
4 Snapshot Button [SNAPSHOT]....... ੬ pg. 22, 26
5 •Power Zoom Lever [T/W] .................. ੬ pg. 28
•Speaker Volume Control [VOL.] ........ ੬ pg. 47
6 Picture Stabilizer Button
[P.STABILIZER]..................................... ੬ pg. 29
7 Program AE Button [P.AE]..................... ੬ pg. 32
8 Fade/Wipe Button [EFFECT] .................੬ pg. 31
9 System Select Switch
[D.S.C./VIDEO] ................ ੬ pg. 18, 22, 46, 52
0 •Rewind Button
[
2
, REW/PAGE–] ...................... ੬ pg. 46, 52
•Retake Rewind Button [RETAKE R]..... ੬ pg. 29
•Quick Review Button [ R] ............. ੬ pg. 29
! •Fast-Forward Button
[
3
, FF/PAGE+] .......................... ੬ pg. 46, 52
•Retake Forward Button [RETAKE F] .... ੬ pg. 29
@ Stop Button [5, STOP] ......................... ੬ pg. 46
# Play/Pause Button
[
4
/6, PLAY/PAUSE]............................. ੬ pg. 46
$ •Select Dial [+, –, PUSH] .............. ੬ pg. 13, 36
•Bright Dial [BRIGHT] ........................ ੬ pg. 21
% MENU/DISPLAY Button ................. ੬ pg. 19, 36
^ •Counter Reset/Memory Button
[COUNTER R/M] .............................. ੬ pg. 48
•Recording Mode Button [SP/EP]......... ੬ pg. 14
& EJECT Switch ....................................... ੬ pg. 15
* Recording Start/Stop Button.................. ੬ pg. 18
( Power Switch .................... ੬ pg. 18, 22, 46, 52
) Battery Release Switch
[BATTERY RELEASE] ............................ ੬ pg. 10
q PUSH Button .......................................੬ pg. 15
Connectors
w DC IN Jack .......................................... ੬ pg. 11
The connectors e to t are located beneath the
cover.
e Video Output Connector ...................... ੬ pg. 50
r Audio Output Connector ..................... ੬ pg. 50
t J Terminal [JLIP (Joint Level Interface Protocol)
Connector]
•It is used to connect the camcorder to a device
such as a personal computer.
For further details consult your nearest JVC
dealer.
•JLIP-controlled editing from camcorder to VCR
is not possible if the VCR is not equipped with a
J terminal.
y Digital Connector ............................... ੬ pg. 53
Indicators
u Tally Lamp........................................... ੬ pg. 18
i Power Lamp ........................................ ੬ pg. 18
Other Parts
o Battery Pack Mount ............................. ੬ pg. 10
p Viewfinder........................................... ੬ pg. 16
Q Grip Strap............................................ ੬ pg. 16
W •Camera sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
•Remote Sensor .................................. ੬ pg. 61
E Video Light .......................................... ੬ pg. 30
R Microphone
For use when recording.
T Eyepiece.............................................. ੬ pg. 60
Y Speaker ............................................... ੬ pg. 47
U LCD Monitor ....................................... ੬ pg. 21
I Shoulder Strap Eyelets .......................... ੬ pg. 17
O Clock Battery Slot ................................ ੬ pg. 12
P Tripod Mounting Socket ....................... ੬ pg. 17
