BladeCenter H Chassis Specifications
# of keyboard ports None (USB-attach)
# of USB 2.0 ports 2 (on Management Module)
Light path diagnostic panel 2 (one on Media Tray, one on Management Module)
Predictive Failure Analysis support
Blades, bridge/switch modules, I/O modules, management modules, power modules,
blower modules, media tray
Power supply size standard 2900W AC
# of power supplies standard /
maximum
2 / 4 hot-swap/redundant
Heat output 1700 BTUs/hr, (500W) min.; 26,000 BTUs/hr (7600W) max.
# of blower modules standard / max. 2 / 2 hot-swap/redundant
Blower module airflow (front-to-back) 430 CFM at 25ºC; 800 CFM at 32ºC or greater
Dimensions (HWD) / weight
15.75” (400mm) H
17.4” (442mm) W
28.0” (711mm) D
41-159 kg
90-350 lbs
Length of limited warranty 3 years (parts and labor) onsite
BladeCenter T Chassis Images
Front View Rear View
BladeCenter T Chassis Specifications
Machine type
8720-2RX (DC)
8730-2RX (AC)
NEBS/ETSI- tested Yes (NEBS Level 3)
Rack form factor 8U
# of DVD/CD Combo drives standard 1 (in Media Tray)
# of diskette drives standard None
Internal tape drives supported None (SAN-attached)
External disk drive support NAS/SAN-attach
HS40 Blade
Servers
HS21 Blade
Server
Hot-Swap
HDDs
Optical Drive
AC Power
Modules
Media Tray
Light Path
Diagnostics
Panel
Management Modules PCI I/O Expansion Unit
Blower
Module
Blower
Module
KVM
Ports
Blower
Module
Blower
Module
Redundant
Power Plugs
Ethernet Switch Modules
