Modular PDUs 1U/0U
Modular PDUs 1U/0UModular PDUs 1U/0U
Modular PDUs 1U/0U
(Up to 32 outlets)
NOTE:
NOTE: NOTE:
NOTE:
1U/0U mounting
brackets shipped with
the unit (optimized for
10000 and 9000 series
racks).
Fixed Cord Extension Bars
NOTE:
NOTE:NOTE:
NOTE:
Two extension bar sticks; each with (7) C13 plugs.
351655-B21
Fixed Cord PDU
NOTE:
NOTE: NOTE:
NOTE:
Four Fixed Cord Extension Bars, and one 24A, HV mPDU L6-30P core.
351655-D72
HP Modular Power Distribution Units (mPDU), Low Volt Model, 24A (100-127 VAC)
NOTE:
NOTE: NOTE:
NOTE:
This mPDU (252663-D71) may also be used to connect the low volt model of
the UPS R3000 XR.
252663-D71
HP Modular Power Distribution Units (mPDU), High Volt Model, 24A (200-240 VAC)
252663-D72
HP Modular Power Distribution Units (mPDU), High Volt Model, 40A (200-240 VAC)
NOTE:
NOTE: NOTE:
NOTE:
This mPDU (252663-B21), 40A model has a hardwired input.
252663-B21
HP Modular Power Distribution Unit (mPDU), High Volt Model, 16A (200-240 VAC)
252663-B24
HP Modular Power Distribution Unit (mPDU), High Volt Model, 40A, Attached Cord
252663-D73
NOTE:
NOTE: NOTE:
NOTE:
This PDU has a detachable input power cord and allows for adaptability to
country specific power requirements. This model may also be used with the high volt
UPSs R3000 XR and R6000 - need to order cable PN 340653-001.
NOTE:
NOTE: NOTE:
NOTE:
Please see the following Modular Power Distribution Unit (Zero-U/1U
Modular PDUs) QuickSpecs for additional options including shorter jumper cables
and country specific power cords:
http://h18000.www1.hp.com/products/quickspecs/11041_na/11041_na.HTML
USB Options
USB OptionsUSB Options
USB Options
HP USB 2-Button Optical Scroll Mouse (Carbonite/Silver)
DC172B
USB 1.44-MB External Diskette Drive (Carbonite)
DC141B
HP ProLiant DL360 G4p
HP ProLiant DL360 G4pHP ProLiant DL360 G4p
HP ProLiant DL360 G4p
Deployment Options
Deployment OptionsDeployment Options
Deployment Options
460W HP redundant power supply with IEC cord only
354587-B21
460W HP redundant power supply with NEMA cord only
NOTE:
NOTE:NOTE:
NOTE:
The HP ProLiant DL360 G4p ships with a single IEC-IEC power cord used for
rack mounting with Power Distribution Units (PDUs). For stand-alone deployments or
installation without a rack, models ship with two power cords: IEC-IEC and NEMA
cords.
354587-001
535W HP redundant power supply with IEC cord only
389830-B21
535W HP redundant power supply with NEMA cord only
NOTE:
NOTE:NOTE:
NOTE:
The HP ProLiant DL360 G4p ships with an IEC-IEC power cord used for rack
mounting with Power Distribution Units (PDUs). For stand-alone deployments or
installation without a rack models ship with two power cords: IEC-IEC and NEMA
cords.
389830-001
Rack Kits
Rack KitsRack Kits
Rack Kits
1U Cable Management Arm
NOTE:
NOTE:NOTE:
NOTE:
Package contains two cable management arms.
365403-B21
QuickSpecs
HP ProLiant DL360 Generation 4p (G4p)
HP ProLiant DL360 Generation 4p (G4p)HP ProLiant DL360 Generation 4p (G4p)
HP ProLiant DL360 Generation 4p (G4p)
Options
